Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Womens Diamond A2-SL custom-butted alloy w/ PowerCurve down tube, oversized seat tube
Suspension Fork
SR Suntour SF14-XCM w/ 100mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Acera, M360 SGS, 8-speed
Front Derailleur
Shimano M190, 34.9mm
Shift Levers
Shimano M310, 8-speed
Cassette
Shimano HG31, 11-34T, 8-speed
Crank
Shimano M171, 42/34/24T w/ chainguard
Bottom Bracket
FSA square taper w/ sealed cartridge bearing
Chain
KMC, HV700, 8-speed
Pedals
Plastic platform
Wheels
Rims
Formula FM21 front / Formula FM32 rear, 32H alloy hubs, Vera Terra DPM18 rims
Tires
Vera Eos, 26" x 2.0", 30 tpi
Brakes
Brakes
ProMax alloy, linear pull front / Promax U-style rear
Brake Levers
Promax 2-finger alloy
Cockpit
Stem
Oval, melt-forged alloy, 25.4mm clamp diameter, 20° rise
Handlebar
Steel rise bar, 6° degree sweep, 25.4mm diameter, 660mm wide, 30mm rise
Headset
FSA 1 1/8" semi-integrated, caged bearings
Seat
Saddle
Oval Mountain w/ satin steel rails
Seatpost
Oval, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM/MD | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.71 mm | 1.59 mm | 1.54 mm |
| Front Center | 589 mm | 624 mm | 645 mm |
| Rake | 38 mm | 38 mm | 38 mm |
| Trail | 75 mm | 75 mm | 75 mm |
| Stack | 586.6 mm | 596 mm | 605.4 mm |
| Reach | 343.5 mm | 375.6 mm | 392.7 mm |
| Top Tube Length | 523.4 mm | 558.4 mm | 578.4 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 406.4 mm | 482 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1009 mm | 1044 mm | 1065 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 34 mm |
| Standover Height | 695 mm | 723 mm | 722 mm |
| Wheels | 26" | 26" | 26" |
Model Overview
Addy Sport 1.1 is part of the Fuji Addy model. There are 52 bikes that carry this model name. Check out the entire range from 2014 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Fitness bikes
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Fitness bikes average weight
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Fuji Addy Sport 1.1 it’s weighing 14 kg (30.86 lbs). At this weight, is much heavier than average. In conclusion, the average Fitness bike weighs 24.56% less than Addy Sport 1.1.
Addy Sport 1.1 components
Fork
The fork installed on this bike is the SunTour XCM model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Fuji Addy Sport 1.1 2014, has a 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
