Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Womens Diamond A2-SL custom-butted alloy w/ PowerCurve down tube, oversized seat tube
Suspension Fork
SR Suntour SF14-XCT w/ 100mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney, TX35, 7-speed
Front Derailleur
Shimano Tourney, TX51, 34.9mm
Shift Levers
Shimano Tourney Revo, 7-speed
Cassette
Shimano Tourney TZ31 freewheel, 14-34T, 7-speed
Crank
Shimano M131, 48/38/28T w/ chainguard
Bottom Bracket
FSA square taper w/ sealed cartridge bearing
Chain
KMC, HV500, 7-speed
Pedals
Plastic platform
Wheels
Rims
Formula FM21 front / Formula FM32 rear, 32H alloy hubs, Vera Terra DPM18 rims
Tires
Vera Eos, 26" x 2.0", 30 tpi
Brakes
Brakes
ProMax alloy, linear pull front / Promax U-style rear
Brake Levers
Promax 2-finger alloy
Cockpit
Stem
Oval, melt-forged alloy, 25.4mm clamp diameter, 20° rise
Handlebar
Steel rise bar, 6° degree sweep, 25.4mm diameter, 660mm wide, 30mm rise
Headset
FSA 1 1/8" semi-integrated, caged bearings
Seat
Saddle
Oval Mountain w/ satin steel rails
Seatpost
Oval, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM/MD | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.71 mm | 1.59 mm | 1.54 mm |
| Front Center | 589 mm | 624 mm | 645 mm |
| Rake | 38 mm | 38 mm | 38 mm |
| Trail | 75 mm | 75 mm | 75 mm |
| Stack | 586.6 mm | 596 mm | 605.4 mm |
| Reach | 343.5 mm | 375.6 mm | 392.7 mm |
| Top Tube Length | 523.4 mm | 558.4 mm | 578.4 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 406.4 mm | 482 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1009 mm | 1044 mm | 1065 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 34 mm |
| Standover Height | 695 mm | 723 mm | 722 mm |
| Wheels | 26" | 26" | 26" |
Model Overview
Addy Sport 1.3 completes the Fuji Addy model. There are 52 bikes that carry this model name. You can easily view all of the Fuji Addy bikes models from 2014, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Fitness bikes
According to our math, the average price for a trustworthy Fitness bike is 656$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fitness bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Fitness bikes average weight
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
much heavier than average, Addy Sport 1.3 has a weight of 13.87 kg (30.58 lbs). In other words, this model is 23.4% heavier than the average Fitness bike.
Addy Sport 1.3 components
Fork
The SunTour XCT is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on Addy Sport 1.3 are the 26″ aluminum type. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
