Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 60mm -
Fork Zoom
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A1-SL alloy front and rear triangle, cold-forged dropout and replaceable hanger
Suspension Fork
Zoom CH-565 w/ 60mm travel
Drivetrain
Rear Derailleur
Shimano Tourney, 7-speed
Front Derailleur
Shimano Tourney, 31.8mm
Shift Levers
Shimano EF41, EZ Fire, 7-speed
Cassette
Shimano freewheel, 14-28T, 7-speed
Crank
Prowheel, alloy, 48/38/28T w/ chainguard
Bottom Bracket
Semi-cartridge bearing
Chain
KMC Z50, 7-speed
Pedals
Resin platform
Wheels
Rims
Vera Terra DPD16 rims, Formula DC-20 front, DC-31 rear disc hub, 14g black spokes
Tires
Vera Eos, 27.5" x 2.1", 30tpi
Brakes
Brakes
Tektro M-280, mechanical disc, 160mm rotors
Brake Levers
Shimano EF41, 2-finger brake/shifter combo
Cockpit
Stem
Steel, +/-25°
Handlebar
Steel riser bar, 25.4mm, 6 sweep, 30mm rise
Grips
Single density Kraton
Headset
1 1/8", caged bearings
Seat
Saddle
Padded MTB, steel rail
Seatpost
Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.46 mm | 1.39 mm |
| Front Center | 609 mm | 617 mm | 636 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Trail | 57 mm | 57 mm | 39 mm |
| Stack | 562 mm | 562 mm | 562 mm |
| Reach | 378 mm | 386 mm | 404.6 mm |
| Top Tube Length | 550 mm | 558 mm | 577 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 381 mm | 432 mm |
| Head Tube Angle | 72 ° | 72 ° | 73 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1057 mm | 1065 mm | 1084 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm |
| Standover Height | 701 mm | 705 mm | 705 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
Model Overview
Adventure 27.5 – ST completes the Fuji Adventure model. 25 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Fuji Adventure 27.5 2023 has a starting price of 318$. Fuji Adventure 27.5 – ST 2023 on the other hand is the most expensive at 318$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Fuji Adventure 27.5 – ST price was 318$. Comparing the average cost of a Hybrid bike to this one, you will see that Adventure 27.5 – ST price is 76.73% lower.
Overview of components
Fork
The fork installed on this bike is the Zoom model. The travel on this model is 60mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the Adventure 27.5 – ST model has aluminum wheels. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Adventure 27.5 – ST has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Fuji Adventure 27.5 – ST bike has 3 sizes, in the range of 151 cm – 179 cm (4.95 ft – 5.87 ft). In short, it won’t be difficult to find the right one for you.
