Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
D6 high modulus carbon w/ high compaction molding system, integrated head tube w/ 1 1/2" lower, oversized PIIS BB-86 shell, double water bottle mounts
Suspension Fork
FC-330 carbon monocoque w/ tapered carbon steerer & carbon dropout
Drivetrain
Rear Derailleur
Shimano Dura Ace, 10-speed
Front Derailleur
Shimano Dura Ace, braze-on mount
Shift Levers
Shimano Dura Ace STI shifter/brake combo, 20-speed Flight Deck compatible
Cassette
Shimano Ultegra, 53/39T 10-speed
Crank
Rotor 3D+F, 39/53T
Bottom Bracket
Rotor Press-Fit BB86/30 sealed cartridge bearing
Chain
KMC X10, 10-speed
Wheels
Rims
Oval 535 aero alloy, 35mm rims, DT Swiss Competition spokes 20/24H, sealed bearing hubs
Tires
Hutchinson Atom Comp, 700x23c, folding
Brakes
Brakes
Oval 700 forged & CNC'd w/ cartridge pads
Brake Levers
Shimano Dura Ace STI
Cockpit
Stem
Oval 700 3D forged 7050 alloy, 31.8mm, +/-6 degrees
Handlebar
Oval 910 full carbon w/ ergo drops, 31.8mm
Headset
Oval 1 1/8"U - 1 1/2"L integrated w/ carbon top cover
Seat
Saddle
Selle Italia SL Kit Carbonio w/ tubular manganese rails
Seatpost
Oval 900 carbon wrap 2-bolt, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.423 mm | 1.428 mm | 1.457 mm | 1.478 mm | 1.492 mm | 1.512 mm |
| Front Center | 58 mm | 58 mm | 58 mm | 59 mm | 61 mm | 61 mm |
| Rake | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm |
| Trail | 103 mm | 100 mm | 96 mm | 93 mm | 93 mm | 90 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 510 mm | 530 mm | 540 mm | 560 mm | 580 mm | 590 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Bottom Bracket Drop | 6 mm | 6 mm | 6 mm | 6 mm | 6 mm | 6 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Altamira 1.0 completes the Fuji Altamira model. Fuji launched 75 bikes of this model so far. Take a sneak peek at all Fuji Altamira bikes models from 2012, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Race bikes
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Altamira 1.0 components
Fork material
Altamira 1.0 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the Altamira 1.0 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Altamira 1.0 has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
