Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 10 Electronic -
Brakes Rim
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Modulus D-6 carbon w/ Integrated head tube w/1 1/2" lower, IST (Integrated Seat Tube), Oversized PIIS BB-86 shell, Double water bottle mounts.
Suspension Fork
FC-330 Carbon Monocoque w/Tapered Carbon steerer & carbon drop out
Drivetrain
Rear Derailleur
Shimano Dura Ace Di2, 10sp
Front Derailleur
Shimano Dura Ace Di2, F-Type-Braze On Mount
Shift Levers
Shimano Dura Ace Di2 Electronic STI shifter/brake combo, 20-speed Flight Deck compatible
Cassette
Shimano Dura Ace, 11-25T 10sp
Crank
Shimano Dura Ace Hollow Tech II, 39/53T
Bottom Bracket
Shimano Press In Bearing system
Chain
Shimano Dura Ace, 10sp
Wheels
Rims
Oval W-945 Carbon Rim w/ Alloy Braking Surface, 58mm rim-700c, Sealed bearings
Tires
Vittoria Open Corsa EVO CX, 700x23c, Kevlar Bead-Folding
Brakes
Brakes
Oval RB-900 CNC Alloy Dual Pivot w/Swiss Stop Carbon Pads
Brake Levers
Shimano Dura Ace Di2 Integrated
Cockpit
Stem
Oval R-900 Carbon Alloy matrix, 31.8mm, +/-6 degrees
Handlebar
Oval R-920 Carbon, 31.8mm
Headset
FSA No. 42 1 1/8"U - 1 1/2"L Integrated w/Carbon Top Cover
Seat
Saddle
Oval SR-900 Sweep w/ Carbon Rails
Seatpost
Ritchey Stubby 1-Bolt, 34.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.42 mm | 1.45 mm | 1.47 mm | 1.48 mm | 1.5 mm |
| Bottom Bracket Height | 270.5 mm | 270.5 mm | 270.5 mm | 270.5 mm | 270.5 mm | 270.5 mm |
| Front Center | 576 mm | 582 mm | 581 mm | 591 mm | 605 mm | 615 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 45 mm | 43 mm | 40 mm | 38 mm | 38 mm | 35 mm |
| Stack | 523.8 mm | 535.1 mm | 546.5 mm | 567.4 mm | 586.6 mm | 607.7 mm |
| Reach | 370.1 mm | 376.7 mm | 377.4 mm | 386.2 mm | 395.5 mm | 404.3 mm |
| Top Tube Length | 522 mm | 537 mm | 552 mm | 567 mm | 582 mm | 597 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 645 mm | 680 mm | 714 mm | 744 mm | 775 mm | 794 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 978 mm | 983 mm | 982 mm | 992 mm | 1007 mm | 1016 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 728 mm | 748 mm | 767 mm | 789 mm | 807 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
Model Overview
Altamira LTD is part of the Fuji Altamira model. 75 bikes variations carry this model name so far. You can easily view all of the Fuji Altamira bikes models from 2011, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Cyclocross bikes average price
If you want to purchase a solid Cyclocross bike, it is important to know that the average cost is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Cyclocross bikes average weight
On a deeper look, we notice that the average weight of a Cyclocross bike is 8.79 kg (19.38 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Altamira LTD weighs 7 kg (15.43 lbs) and is much lighter than the average. In short, the average Cyclocross bike weight is 25.57% higher than this one.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Fuji Altamira LTD 2011, has a 700c carbon model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Altamira LTD has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Fuji Altamira LTD bike has 6 sizes, in the range of 158 cm – 194 cm (5.18 ft – 6.36 ft). In conclusion, you won’t have a problem finding one that suits you.
