Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
D6 high modulus carbon w/ high compaction molding system, integrated head tube w/ 1 1/2" lower, oversized PIIS BB-86 shell, double water bottle mounts
Suspension Fork
FC-330 carbon monocoque w/ tapered carbon steerer & carbon dropout
Drivetrain
Rear Derailleur
Shimano Dura Ace, 10-speed
Front Derailleur
Shimano Dura Ace, braze-on mount
Shift Levers
Shimano Dura Ace STI shifter/brake combo, 20-speed Flight Deck compatible
Cassette
Shimano Dura Ace, 11-25T 10-speed
Crank
Rotor 3D, 39/53T
Bottom Bracket
Rotor Press-Fit BB86/30 sealed cartridge bearing
Chain
KMC X10SL Ni-Ti Plated, 10-speed
Wheels
Rims
DT Swiss RC 32 full carbon clincher
Tires
Hutchinson Atom Comp, 700x23c, folding
Brakes
Brakes
TRP 970SL-White dual pivot, forged magnesium w/ Ti Hardware w/ SwissStop pads
Brake Levers
Shimano Dura Ace STI
Cockpit
Stem
Oval 700 3D forged 7050 alloy, 31.8mm, +/-6 degrees
Handlebar
Oval 930 full carbon, 31.8mm
Headset
Oval 1 1/8"U - 1 1/2"L integrated w/ carbon top cover
Seat
Saddle
Selle Italia Monolink Team Edition w/ carbon rails
Seatpost
Selle Italia Monolink carbon, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.423 mm | 1.428 mm | 1.457 mm | 1.478 mm | 1.492 mm | 1.512 mm |
| Front Center | 58 mm | 58 mm | 58 mm | 59 mm | 61 mm | 61 mm |
| Rake | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm |
| Trail | 103 mm | 100 mm | 96 mm | 93 mm | 93 mm | 90 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 510 mm | 530 mm | 540 mm | 560 mm | 580 mm | 590 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Bottom Bracket Drop | 6 mm | 6 mm | 6 mm | 6 mm | 6 mm | 6 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Altamira LTD Team Edition is part of the Fuji Altamira model. Fuji released 75 bikes variations of this model so far. You can easily view all of the Fuji Altamira bikes models from 2012, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Cyclocross bikes
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the Altamira LTD Team Edition bike is equipped with the 700c carbon model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Altamira LTD Team Edition has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
