Fuji Ambient EVO 29 EQP 2022
2022 E-bike
Estimate price |
4,816$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Suntour XCR Air
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Power Tube 500Wh with 2A charger -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL alloy front and rear triangle with down tube for integrated Bosch Power Tube 625-500Wh battery, Bosch Gen.4 motor cover, tapered 1 1/8" - 1.5" head tube, post disc mount, Boost 148 x 12mm cold-forged dropout and replaceable hanger
Suspension Fork
SR Suntour XCR34-Air 29, Lockout, tapered alloy steerer, Boost 110 x 15mm thru axle, travel 120mm, 34mm stanchions
Drivetrain
Rear Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano Deore, 11-51T, 11-speed
Crank
FSA CK-745/IS, Bosch Gen.4, 32T, with chainguard, for Boost
Bottom Bracket
Bosch System ISIS drive
Chain
Shimano CN-HG601-11, 11-speed
Pedals
Alloy platform, chromoly axle
Wheels
Rims
Shimano MT400-Boost CL 15mm thru axle disc, 32H, front / Shimano MT400-Boost CL 12mm thru axle disc, 32H, rear, 14/15g stainless steel spokes, WTB ST i29 TCS 2.0 double wall 29" rims
Tires
Continental Ruban, 58-622
Brakes
Brakes
TRP Slate-T4 and X2, 4-piston front, 2-piston rear hydraulic disc, rotors: 203mm front and rear
Brake Levers
TRP Slate-T4, 2 finger lever
Cockpit
Stem
3D-forged 6061 alloy, 7°, 31.8mm clamp, length: 17" - 35mm, 19"- 45mm, 21" - 60mm
Handlebar
Oval Concepts 205 flat bar, 6061 alloy, +/- 15mm rise, 9° sweep, 31.8mm clamp, width: 760mm
Grips
WTB Waffel, single LO, dual density Kraton
Headset
FSA NO.57B, 1 1/8" - 1.5", retainer bearings
Seat
Saddle
WTB High Tail Trail, Comp, e-Bike specific saddle, steel rail
Seatpost
Fuji Alloy, 6061 alloy micro adjust, 30.9mm diameter
Motor & Battery
Motor
Bosch Performance CX, 4th generation mid-motor, 250W rated power, 85Nm of torque, 25km/h maximum assist
Battery
Bosch Power Tube 500Wh with 2A charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.42 mm | 1.34 mm |
| Bottom Bracket Height | 326 mm | 326 mm | 326 mm |
| Front Center | 733 mm | 754 mm | 784 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 98 mm | 98 mm | 98 mm |
| Stack | 632 mm | 637 mm | 641 mm |
| Reach | 429 mm | 448 mm | 477 mm |
| Top Tube Length | 618 mm | 638 mm | 668 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 483 mm | 533.4 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 120 mm | 125 mm | 130 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1167 mm | 1188 mm | 1218 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm |
| Standover Height | 834 mm | 833 mm | 859 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Ambient EVO 29 EQP completes the Fuji E Ambient model. Fuji launched 25 e-bikes of this model so far. You can easily view all of the Fuji E Ambient e-bikes models from 2022, here.
Model range prices
Fuji Ambient 29 EQP 2022 is the most affordable e-bike of this model and has a price of 3344$. On the other hand, Fuji Ambient 29 EVO EQP 2022, is the most expensive and costs 4458$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail e-bikes average price
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Fuji Ambient EVO 29 EQP price was 4458$. Comparing the average cost of a Trail e-bike to this one, you will see that Ambient EVO 29 EQP price is 32.48% higher.
Ambient EVO 29 EQP components
Fork
The Suntour XCR Air is included from the factory. It has a travel distance of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Wheels
The Ambient EVO 29 EQP 2022 e-bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Ambient EVO 29 EQP has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Fuji Ambient EVO 29 EQP e-bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
