Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 80mm -
Fork Fox Float 32
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL Quarternary-phase custom-butted alloy, hydroformed top and down tube, tapered 1 1/8" - 1.5" head tube
Suspension Fork
Fox 32 FLOAT Evolution CTD w/ 15mm thru axle, tapered alloy steerer, 80mm travel (13" & 15") 100mm travel (17" & 19")
Rear Shock
FOX Evolution CTD
Drivetrain
Rear Derailleur
Shimano Deore XT, M781 SGS Shadow, 10-speed
Front Derailleur
Shimano Deore, M591, 34.9mm
Shift Levers
Shimano SLX, M670 Rapid Fire, 20/30-speed
Cassette
Shimano Deore HG62, 11-36T, 10-speed
Crank
Shimano Deore, M552 w/ integrated spindle, 42/32/24
Bottom Bracket
Shimano cartridge bearings
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Shimano SLX M678 front / M675 rear, 32H Center Lock disc hubs, Sun Inferno 23 rims
Tires
Schwalbe Racing Ralph, 26" x 2.1" folding, 67 tpi
Brakes
Brakes
Shimano Deore M596 hydraulic, 160mm rotor
Brake Levers
Shimano Deore M596 hydraulic
Cockpit
Stem
Oval M613, 3D-forged alloy, 31.8mm clamp diameter, 6° rise
Handlebar
Oval M600, alloy riser bar, 9° sweep, 31.8mm diameter, 680mm wide, 15mm rise
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval Womens W600 w/ hollow CrMo rails
Seatpost
Oval M600, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.47 mm | 1.39 mm | 1.32 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm |
| Stack | 548.3 mm | 548.3 mm | 548.4 mm | 548.4 mm |
| Reach | 360.2 mm | 374.2 mm | 394.3 mm | 415.1 mm |
| Top Tube Length | 518 mm | 532 mm | 553 mm | 573 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 330 mm | 381 mm | 432 mm | 482 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 125 mm | 125 mm | 125 mm | 125 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1027 mm | 1041 mm | 1062 mm | 1082 mm |
| Standover Height | 738 mm | 738 mm | 749 mm | 749 mm |
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
Belle 1.1 completes the Fuji Belle model. There are 7 bikes that carry this model name. You can easily view all of the Fuji Belle bikes models from 2014, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Fuji Belle 1.1 it’s weighing 12.5 kg (27.56 lbs). At this weight, is slightly heavier than average. In short, the average Crosscountry bike weight is 0.81% lower than this one.
Belle 1.1 components
Fork
The Fox Float 32 is included from the factory. It has a travel distance of 80mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
When leaving the production line, the Belle 1.1 model has 26″ aluminum wheels. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
