Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCR 34
-
Groupset Deore, FSA -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 175cm
MD
173cm - 180cm
LG
178cm - 185cm
XL
173cm - 193cm
XXL
190cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL super-butted alloy, smooth welds, Boost 148x12mm
Suspension Fork
Suntour XCR 34 LO Coil, tapered steerer, Boost 110x15mm, 120mm
Drivetrain
Rear Derailleur
Shimano Deore, shadow plus
Front Derailleur
N/A
Shift Levers
Shimano Deore, Rapid Fire, 1 x 10-speed
Cassette
Shimano HG500, 11-42T
Crank
FSA Gamma Pro, 30T
Bottom Bracket
FSA Mega EXO, threaded
Chain
KMC X10
Pedals
N/A
Wheels
Rims
WTB ST i35 TCS 2.0 27.5"+ 32H rims, Shimano MT400 front hub, MT400 rear hub, stainless black spokes
Tires
Maxxis Rekon+, 27.5" x 2.8", 60tpi, EXO, Tubeless Ready, folding
Brakes
Brakes
Shimano MT200, 180mm rotors
Brake Levers
Shimano MT201
Cockpit
Stem
Oval Concepts 600AM, alloy, 0°
Handlebar
Oval Concepts 215 riser bar, alloy, ± 15mm rise, 760mm
Grips
WTB Waffel Lock on
Headset
FSA 1 1/8" - 1.5", sealed bearings
Seat
Saddle
WTB Volt Sport
Seatpost
Oval Concepts 300, alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.44 mm | 1.36 mm | 1.32 mm | 1.29 mm |
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm | 300 mm | 300 mm |
| Front Center | 698 mm | 724 mm | 749 mm | 775 mm | 805 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 92 mm | 92 mm | 92 mm | 92 mm | 83 mm |
| Stack | 610 mm | 619.2 mm | 619.2 mm | 628.5 mm | 637.7 mm |
| Reach | 407.5 mm | 429.9 mm | 454.9 mm | 477.2 mm | 494.6 mm |
| Top Tube Length | 583 mm | 608 mm | 633 mm | 658 mm | 678 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 432 mm | 465 mm | 513 mm | 543 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1123 mm | 1150 mm | 1175 mm | 1201 mm | 1231 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 631 mm | 667 mm | 683 mm | 685 mm | 707 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 165 cm | 173 cm | 178 cm | 173 cm | 190 cm |
| Rider Max Height | 175 cm | 180 cm | 185 cm | 193 cm | 198 cm |
About this model
Bighorn 27.5+ 1.5 is part of the Fuji Bighorn model. Fuji released 21 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
The most economical model, the Fuji Bighorn 27.5+ 1.7 2020 has a starting price of 1099$. Fuji Bighorn 27.5+ 1.3 2020 on the other hand is the most expensive at 1499$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2020 for 1299$. Doing a quick comparison, we notice that Bighorn 27.5+ 1.5 price is 112.63% smaller than the average cost of a Trail bike.
Overview of components
Fork
This bike has the SunTour XCR 34 fork installed. The fork’s travel is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Fuji Bighorn 27.5+ 1.5 2020, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Bighorn 27.5+ 1.5 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Bighorn 27.5+ 1.5 comes in 5 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
