Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 130mm -
Fork Suntour XCR 34
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 170cm
MD
168cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
XXL
185cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL super-butted alloy, smooth welds, Boost 148x12mm
Suspension Fork
Suntour XCR 34 LO Coil, tapered alloy steerer, Boost 110x15mm, 130mm OR RST 110-15 Coil w/LO
Drivetrain
Rear Derailleur
Shimano Deore, shadow plus OR SunRAce MS300
Shift Levers
Shimano Deore, 1 x 11-speed OR SunRace MX33N
Cassette
Sunrace, 11-50T
Crank
Shimano Deore, 30T OR FSA Gamma Pro 1X MegaExo
Bottom Bracket
Shimano, threaded OR FSA MegaExo
Chain
KMC X11
Wheels
Rims
WTB ST i30 TCS 2.0 29"+ 32H rims, Shimano MT400 front hub, MT400 rear hub, DT Swiss Industry spokes OR Formula DC-711 front hub, DC-3248 rear hub
Tires
Maxxis Minion DHF, 29" x 2.50" WT, 60tpi, EXO, Tubeless Ready, folding, Maxxis Dissector, 29" x 2.40" WT, 60tpi, EXO, Tubeless Ready, folding
Brakes
Brakes
Shimano MT200, 180mm rotors OR Tektro HD-M275 OR Promax DSK-923
Brake Levers
Shimano MT201 OR Tektro HD-M275 OR Promax DSK-923
Cockpit
Stem
Fuji, alloy, 0°
Handlebar
Fuji riser bar, alloy, 15mm rise, 760mm
Grips
WTB Waffel Lock on
Headset
FSA 1 1/8" - 1.5", sealed bearings
Seat
Saddle
WTB Volt Medium Steel
Seatpost
Fuji, alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.44 mm | 1.36 mm | 1.32 mm | 1.29 mm |
| Bottom Bracket Height | 319 mm | 319 mm | 319 mm | 319 mm | 319 mm |
| Front Center | 698 mm | 724 mm | 749 mm | 775 mm | 805 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm | 91 mm |
| Stack | 610 mm | 619.2 mm | 619.2 mm | 628.5 mm | 637.7 mm |
| Reach | 407.5 mm | 429.9 mm | 454.9 mm | 477.2 mm | 494.6 mm |
| Top Tube Length | 583 mm | 608 mm | 633 mm | 658 mm | 678 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 432 mm | 465 mm | 513 mm | 543 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1123 mm | 1150 mm | 1175 mm | 1201 mm | 1231 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 631 mm | 667 mm | 683 mm | 685 mm | 707 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 168 cm | 175 cm | 180 cm | 185 cm |
| Rider Max Height | 170 cm | 178 cm | 183 cm | 188 cm | 196 cm |
About this model
Bighorn 29 1.5 is part of the Fuji Bighorn model. 21 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Fuji Bighorn 1.7 2022 is the most economical model, with a starting price of 1018$. Fuji Bighorn 29 1.3 2022 on the other hand costs 1999$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Fuji released this model in 2022, its price was 1499$. If we compare this with the average Trail bike cost we notice that the price is 84.26% lower.
Bighorn 29 1.5 components
Fork
The Bighorn 29 1.5 comes factory-installed with the Suntour XCR 34 fork. This has a travel range of 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The wheels on Bighorn 29 1.5 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Bighorn 29 1.5 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 160 cm – 196 cm (5.25 ft – 6.43 ft). In short, it won’t be difficult to find the right one for you.
