Fuji Blackhill EVO 27.5+ 1.5 2023
2023 E-bike
Estimate price |
4,699$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Fork Suntour X1
-
Groupset Deore, FSA -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Power Tube 500Wh with 2A charger -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL alloy front and rear triangle with down tube for integrated Bosch Power Tube 625-500Wh battery, Bosch Gen.4 motor cover, 4-bar suspension system, tapered 1 1/8" - 1.5" head tube, post disc mount, Boost 148 x 12mm cold-forged dropout and replaceable hanger
Suspension Fork
SR Suntour Zeron 27.5+, Lockout, Rebound, Coil, tapered alloy steerer, Boost 110 x 15mm thru axle, travel 150mm, 35mm stanchions
Rear Shock
Suntour TriAir 3-CR, lockout, 210 x 50mm
Drivetrain
Rear Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano, 11-51T, 11-speed
Crank
FSA CK-745/IS, Bosch Gen.4, 32T, with chainguard, for Boost
Bottom Bracket
Bosch System ISIS drive
Chain
Shimano CN-HG601-11, 11-speed
Wheels
Rims
Shimano MT400-Boost CL 15mm thru axle disc, 32H, front / Shimano MT400-Boost CL 12mm thru axle disc, 32H, rear, 14/15g stainless steel spokes, WTB ST i35 TCS 2.0 double wall 27.5" rims
Tires
Continental Trail King, 65-584, ShieldWall, foldable, TL OR WTB Ranger
Brakes
Brakes
TRP Slate-T4 and X2, 4-piston front, 2-piston rear hydraulic disc, rotors: 203mm front and rear
Brake Levers
TRP Slate-T4, 2 finger lever
Cockpit
Stem
Oval Concepts 600AM, 3D-forged 6061 alloy, 0°, 31.8mm clamp, length: 17", 19" - 35mm, 21" - 45mm
Handlebar
Oval Concepts 205 flat bar, 6061 alloy, +/- 5mm rise, 9° sweep, 31.8mm clamp, width: 760mm
Grips
WTB Waffel, single LO, dual density Kraton
Headset
FSA NO.57EP, 1 1/8” - 1.5”, ACB bearings
Seat
Saddle
WTB High Tail Trail, Comp, e-Bike specific saddle, steel rail
Seatpost
KS LEV-SI Dropper, 30.9mm, remote, travel: 17", 19" - 125mm, 21" - 150mm
Motor & Battery
Motor
Bosch Performance CX, 4th generation mid-motor, 250W rated power, 85Nm of torque, 25km/h, 20mph (USA) maximum assist
Battery
Bosch Power Tube 500Wh with 2A charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.38 mm | 1.33 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm |
| Front Center | 753 mm | 759 mm | 779 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 97 mm | 109 mm | 104 mm |
| Stack | 609 mm | 619 mm | 616 mm |
| Reach | 435 mm | 448.7 mm | 464.7 mm |
| Top Tube Length | 618 mm | 633 mm | 653 mm |
| Seat Tube Angle | 73.3 ° | 73.3 ° | 73.3 ° |
| Seat Tube Length | 432 mm | 483 mm | 534 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm |
| Chainstay Length | 478 mm | 478 mm | 478 mm |
| Wheelbase | 1231 mm | 1236 mm | 1256 mm |
| Bottom Bracket Drop | 17 mm | 17 mm | 17 mm |
| Standover Height | 826 mm | 832 mm | 839 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Blackhill EVO 27.5+ 1.5 is a Fuji E Blackhill model. Fuji launched 11 e-bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Fuji Blackhill EVO 27.5+ 1.5 2023 is the most affordable e-bike of this model and has a price of 4699$. On the other hand, Fuji Blackhill EVO 29 EQP 2023, is the most expensive and costs 5294$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Enduro e-bikes average price
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2023 and its price was 4699$. Doing a quick comparison, we notice that Blackhill EVO 27.5+ 1.5 price is 1.83% lower than the average cost of an Enduro e-bike.
Blackhill EVO 27.5+ 1.5 components
Fork
The Blackhill EVO 27.5+ 1.5 comes factory-installed with the Suntour X1 fork. This has a travel range of 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
The fork on this e-bike is made out of aluminum, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels
When leaving the production line, the Blackhill EVO 27.5+ 1.5 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Blackhill EVO 27.5+ 1.5 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
