Fuji Blackhill Evo 29 1.5 USA 2019
2019 E-bike
Estimate price |
3,999$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork SunTour RAIDON
-
Groupset Deore, FSA -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch Power Tube 500Wh w/ charger -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 159cm
MD
158cm - 162cm
LG
161cm - 166cm
XL
165cm - 171cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL alloy front and rear triangle w/ down tube for integrated Bosch Power Tube 500Wh battery, custom Bosch motor cover, 4-bar suspension system, tapered 1 1/8" - 1.5" head tube, post disc mount, Boost 148 x 12mm cold-forged dropout and replaceable hanger
Suspension Fork
Suntour Raidon LOR 29/27+, tapered alloy steerer, Boost 110 x 15mm thru axle, travel 120mm, 34mm stanchions
Rear Shock
Suntour DUAir LO-R8, lockout, 210 x 50mm
Drivetrain
Rear Derailleur
Shimano Deore M6000 Shadow Plus
Shift Levers
Shimano Deore M6000, Rapid Fire
Cassette
Shimano Deore HG500, 11-42T, 10-speed
Crank
FSA CK-745/IS / 14T / w/ chainguard
Bottom Bracket
Bosch System ISIS drive
Chain
KMC e10S w/ Missing Link, 10-speed
Wheels
Rims
Shimano MT400-Boost CL 15mm TA disc, 32H, front / Shimano MT400-Boost CL 12mm thru axle disc, 32H, rear, 14/15g stainless steel spokes, WTB STp i25 TCS double wall rims
Tires
WTB Vigilante, DNA, 29" x 2.3"
Brakes
Brakes
TRP Slate T4, 4 Piston hydraulic disc, rotors: 203mm front, 180mm rear
Brake Levers
TRP Slate T4, hydraulic disc 2 finger levers
Cockpit
Stem
Oval Concepts 600AM, 3D-forged 6061 alloy, 0 degree, 31.8mm clamp
Handlebar
Oval Concepts 205 flat bar, 6061 alloy, +/- 5mm rise, 9 degree sweep, 31.8mm clamp
Grips
Oval Concepts 634 Trail, single LO, dual density Kraton
Headset
FSA NO.9M, 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval Concepts 238 Trail, steel rail
Seatpost
Oval OE, 6061 alloy micro adjust, 30.9mm diameter
Motor & Battery
Motor
Bosch Performance CX, mid-motor, 250W rated power, 20mph or 25kph maximum assist
Battery
Bosch Power Tube 500Wh w/ charger
Remote
Bosch Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.539 mm | 1.424 mm | 1.389 mm | 1.33 mm | 1.312 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 699 mm | 731 mm | 752 mm | 772 mm | 800 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 102 mm | 102 mm | 104 mm | 104 mm | 104 mm |
| Stack | 611 mm | 611 mm | 621 mm | 621 mm | 639 mm |
| Reach | 397 mm | 429 mm | 447 mm | 467 mm | 487 mm |
| Top Tube Length | 568 mm | 600 mm | 620 mm | 640 mm | 656 mm |
| Seat Tube Angle | 75.5 ° | 74.5 ° | 74.5 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 432 mm | 483 mm | 534 mm | 584 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 120 mm | 140 mm |
| Chainstay Length | 486 mm | 486 mm | 486 mm | 486 mm | 486 mm |
| Wheelbase | 1183 mm | 1215 mm | 1236 mm | 1256 mm | 1284 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 767 mm | 777 mm | 780 mm | 783 mm | 818 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 158 cm | 161 cm | 165 cm | cm |
| Rider Max Height | 159 cm | 162 cm | 166 cm | 171 cm | cm |
Model Overview
Blackhill Evo 29 1.5 USA belongs to the Fuji E Blackhill model. There are 10 e-bikes that carry this model name. Take a sneak peek at all Fuji E Blackhill e-bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Fuji Blackhill Evo 29 1.5 USA 2019 has a starting price of 3999$. Fuji Blackhill Evo LT 27.5+ 1.5 USA 2019 on the other hand is the most expensive at 4499$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3999$. Doing a quick comparison, we notice that Blackhill Evo 29 1.5 USA price is 18.84% higher than the average cost of a Trail e-bike.
Blackhill Evo 29 1.5 USA components
Fork
The SunTour RAIDON is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
Blackhill Evo 29 1.5 USA has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the Blackhill Evo 29 1.5 USA model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Blackhill Evo 29 1.5 USA is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
