Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Force -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL custom-butted alloy w/ shaped top tube & integrated tapered head tube w/ 1 1/2" lower, oversized 34.9mm round seat tube, PIIS BB86 shell, double water bottle mounts
Suspension Fork
FC-770 carbon blade, alloy crown w/ tapered alloy steerer & alloy dropouts
Drivetrain
Rear Derailleur
SRAM Force CX-1, 11-speed
Front Derailleur
none
Shift Levers
SRAM Force CX-1 Double Tap w/ hydraulic reservior, 11-speed
Cassette
SRAM PG-1170, 11-28T, 11-speed
Crank
SRAM Force CX-1, 44T
Bottom Bracket
SRAM Force, press-fit, BB86
Chain
KMC X11L, 11-speed
Pedals
N/A
Wheels
Rims
Oval 527CX disc clincher wheelset, 24 / 28h
Tires
Challenge Grifo 700 x 32, 60tpi, folding
Brakes
Brakes
SRAM Force CX-1 Hydraulic, 160mm / 140mm rotors
Brake Levers
SRAM Force CX-1 Double Tap w/ hydraulic reservior
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, +/- 7°
Handlebar
Oval Concepts 310, butted 6061 alloy, 31.8mm
Headset
FSA, 1 1/8" upper - 1 1/2" lower, integrated
Seat
Saddle
Oval Concepts R700 w/ chromoly-Ti hollow rails
Seatpost
Oval Concepts 905, carbon wrapped alloy, 27.2mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.37 mm | 1.42 mm | 1.48 mm | 1.49 mm | 1.5 mm | 1.51 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 277 mm | 277 mm | 279 mm | 279 mm |
| Front Center | 583 mm | 599 mm | 600 mm | 590 mm | 605 mm | 621 mm | 636 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 65 mm | 65 mm | 62 mm | 60 mm | 61 mm | 59 mm | 59 mm |
| Stack | 514 mm | 519 mm | 539 mm | 549 mm | 568 mm | 585 mm | 604 mm |
| Reach | 366 mm | 380 mm | 379 mm | 371 mm | 381 mm | 390 mm | 399 mm |
| Top Tube Length | 505 mm | 520 mm | 530 mm | 540 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 110 mm | 130 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 998 mm | 1014 mm | 1015 mm | 1006 mm | 1021 mm | 1038 mm | 1053 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 67 mm | 67 mm | 65 mm | 65 mm |
| Standover Height | 744 mm | 756 mm | 774 mm | 787 mm | 808 mm | 825 mm | 845 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Cross 1.1 Disc is a Fuji Cross model. Fuji released 46 bikes variations of this model so far. You can easily view all of the Fuji Cross bikes models from 2015, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Cyclocross bikes
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Cyclocross bikes average weight
Cyclocross bikes weigh an average of 8.79 kg (19.38 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Fuji Cross 1.1 Disc it’s weighing 8.8 kg (19.4 lbs). At this weight, is slightly heavier than average. In conclusion, the average Cyclocross bike weighs 0.11% less than Cross 1.1 Disc.
Overview of components
Fork material
Cross 1.1 Disc has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Fuji Cross 1.1 Disc 2015, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Cross 1.1 Disc is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
