Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL custom-butted alloy w/ shaped top tube & integrated tapered head tube w/ 1 1/2" lower, oversized 34.9mm round seat tube, PIIS BB86 shell, double water bottle mounts
Suspension Fork
FC-770 carbon blade, alloy crown w/ tapered alloy steerer & alloy dropouts
Drivetrain
Rear Derailleur
Shimano Tiagra, 10-speed
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra, STI, 10-speed
Cassette
SunRace, 11-28T, 10-speed
Crank
Oval Concepts 520, forged 6066 arms, 46/36T
Bottom Bracket
Oval Concepts, BB86 press-fit
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Vera Corsa DPD22, 24 / 28h Formula disc hubs
Tires
Challenge Grifo 700 x 32, 60tpi, folding
Brakes
Brakes
Avid BB5 mechanical disc for road, 160mm / 140mm rotors
Brake Levers
Shimano Tiagra, STI
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, +/- 7°
Handlebar
Oval Concepts 310, butted 6061 alloy, 31.8mm
Headset
FSA, 1 1/8" upper - 1 1/2" lower, integrated
Seat
Saddle
Oval Concepts R500 w/ chromoly hollow rails
Seatpost
Oval Concepts 300, 3D-forged 6061 alloy, 27.2mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.37 mm | 1.42 mm | 1.48 mm | 1.49 mm | 1.5 mm | 1.51 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 277 mm | 277 mm | 279 mm | 279 mm |
| Front Center | 583 mm | 599 mm | 600 mm | 590 mm | 605 mm | 621 mm | 636 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 65 mm | 65 mm | 62 mm | 60 mm | 61 mm | 59 mm | 59 mm |
| Stack | 514 mm | 519 mm | 539 mm | 549 mm | 568 mm | 585 mm | 604 mm |
| Reach | 366 mm | 380 mm | 379 mm | 371 mm | 381 mm | 390 mm | 399 mm |
| Top Tube Length | 505 mm | 520 mm | 530 mm | 540 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 110 mm | 130 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 998 mm | 1014 mm | 1015 mm | 1006 mm | 1021 mm | 1038 mm | 1053 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 67 mm | 67 mm | 65 mm | 65 mm |
| Standover Height | 744 mm | 756 mm | 774 mm | 787 mm | 808 mm | 825 mm | 845 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Cross 1.5 Disc is part of the Fuji Cross model. Fuji released 46 bikes variations of this model so far. Take a sneak peek at all Fuji Cross bikes models from 2015, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Cyclocross bikes average price
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, even if your budget is less than the average, you might still be able to get a top-quality Cyclocross bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Cyclocross bikes average weight
On a deeper look, we notice that the average weight of a Cyclocross bike is 8.79 kg (19.38 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
considerably heavier than average, Cross 1.5 Disc has a weight of 10.02 kg (22.09 lbs). In conclusion, the average Cyclocross bike weighs 13.99% less than Cross 1.5 Disc.
Cross 1.5 Disc components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the Cross 1.5 Disc bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Cross 1.5 Disc has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
