Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 50mm -
Fork SunTour
-
Groupset Alivio, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Altair 1 aluminum with double water bottle mounts
Suspension Fork
SR Suntour SF9-CR-8R V2 suspension, 50mm travel
Drivetrain
Rear Derailleur
Shimano Alivio RD-M410, Dual Pull
Front Derailleur
Shimano Alivio FD-M412
Shift Levers
Shimano ST-EF60 Integrated shifters
Cassette
Shimano CS-HG40, 11-32T 8-speed
Crank
Shimano FC-M191 forged alloy crank, 28/38/48T w/ Chainguard
Bottom Bracket
Sealed Cartridge Bearing ST
Chain
KMC Z-72
Pedals
Wellgo LU-975 w/Kraton no slip inserts
Wheels
Front Hub
Formula sealed alloy, 36H QR
Rear Hub
Formula sealed alloy, 36H QR
Rims
Alex ID-19, Double Wall CNC side wall
Spokes
14G Stainless Steel
Tires
Kenda Hybrid, 700 x 35c
Brakes
Brakes
Shimano V-brake BR-M422 Forged alloy, linear pull
Brake Levers
Shimano ST-EF60 Integrated
Cockpit
Stem
Fuji Trekking, alloy, adjustable angle
Handlebar
Fuji ATB 50mm rise, alloy
Headset
Fuji Trekking, 1 1/8", Sealed
Seat
Saddle
WTB Freedom Relax Sport
Seatpost
Fuji suspension 27.2, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm | 277 mm | 277 mm |
| Front Center | 623 mm | 623 mm | 623 mm | 628 mm | 628 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 40 mm |
| Top Tube Length | 538 mm | 549 mm | 559.2 mm | 562.8 mm | 577.4 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 431 mm | 482 mm | 533 mm | 584 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 71.5 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 160 mm | 190 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1062 mm | 1062 mm | 1062 mm | 1067 mm | 1067 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 737 mm | 763 mm | 793 mm | 829 mm | 872 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
CROSSTOWN 1.0-EURO is part of the Fuji Crosstown model. 134 bikes variations carry this model name so far. You can easily view all of the Fuji Crosstown bikes models from 2010, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Comfort bikes average price
Our math shows that the average cost of a dependable Comfort bike is 360$. However, this doesn’t mean that if you spend less money on a Comfort bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The SunTour is included from the factory. It has a travel distance of 50mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When it comes to wheels, the CROSSTOWN 1.0-EURO bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji CROSSTOWN 1.0-EURO is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
