Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 75mm -
Fork SunTour XCT
-
Groupset Alivio, Suntour SR -
Suspension Full -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Altair 1 Aluminum with PowerDiamond down tube, extruded seat mast, water bottle mount
Suspension Fork
SR SunTour XCT with preload,75mm Travel
Rear Shock
ToughShock MA coil-over rear shock
Drivetrain
Rear Derailleur
NEW Shimano Alivio
Front Derailleur
SR SunTour TP-17, 31.8mm top pull
Shift Levers
Shimano Acera EZ Fire brake/shifter, 24-speed
Cassette
SR SunTour, 11-32T 8-speed
Crank
SR SunTour XCC-150 forged Al, 24/34/42T w/chainguard
Bottom Bracket
Sealed Cartridge, 122.5MM
Chain
KMC Z-72
Pedals
Wellgo ATB, Toe Clip Attachable
Wheels
Front Hub
Fuji Sealed Bearing Disc, 32H
Rear Hub
Fuji Sealed Bearing Disc, 32H
Rims
Alex DP-17 Double Wall Al Disc
Spokes
Stainless Steel, 14 gauge
Tires
Kenda, 26 x 2.1"
Brakes
Brakes
ProMax mechanical disc with centering adjuster
Brake Levers
Shimano Acera EZ Fire brake/shifter
Cockpit
Stem
Fuji Forged Al w/ removable faceplate
Handlebar
Fuji Aluminum Riser
Headset
Ritchey 1 1/8" AheadSet w/30mm spacers
Seat
Saddle
Fuji Comp MTB with Cro-Moly rails
Seatpost
Fuji Aluminum micro-adjust, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm | 331 mm |
| Front Center | 599 mm | 619 mm | 650 | 680 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 538 mm | 558 mm | 588 mm | 618 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 115 mm | 140 mm | 140 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1021 mm | 1041 mm | 1072 mm | 1102 mm |
| Bottom Bracket Drop | 5 mm | 5 mm | 5 mm | 5 mm |
| Standover Height | 730 mm | 763 mm | 805 mm | 822 mm |
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
Discovery 1.0 completes the Fuji Discovery model. There are 6 bikes that carry this model name. Check out the entire range from 2006 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Crosscountry bikes
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Discovery 1.0 weighs 14.6 kg (32.19 lbs) and is much heavier than the average. In other words, this model is 17.74% heavier than the average Crosscountry bike.
Discovery 1.0 components
Fork
This bike has the SunTour XCT fork installed. The fork’s travel is 75mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The Discovery 1.0 2006 bike is equipped with 26″ aluminum wheels when leaving the factory. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
