Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset GRX 800, FSA -
Suspension Rigid -
Motor Fazua 250W 55Nm mid-drive -
Battery Fazua Evation 250Wh with charger -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 170cm
MD
168cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL Super-Butted Aluminum, internal cable routing, , Fazua compatible, integrated head tube w/ 1 1/2" upper and lower, double water bottle mounts, flat-mount disc system, dropout w/ 12mm replaceable hanger
Suspension Fork
FC-440 Cross carbon monocoque, 12mm thru-axle w/ flat-mount disc tabs, tapered steerer, rack/water bottle mounts
Drivetrain
Rear Derailleur
Shimano GRX RX812 GS
Shift Levers
Shimano GRX Dual Control Hydraulic, 11-speed
Cassette
Shimano HG-5100-11, 11-42T
Crank
FSA CK-746-1/IS, 42T Megatooth, for Fazua
Chain
Shimano HG601-11, HyperGlide-X, 11-speed
Wheels
Rims
WTB HTZ i23 TCS 2.0, 32/32h, 12mm thru-axle cartridge bearing hubs for e-gravel
Tires
WTB Riddler, 700x45c, Dual DNA Compound, Lightweight Tubeless Casing, TCS Aramid Bead, Tan walls
Brakes
Brakes
Shimano GRX Hydraulic, 160/160mm rotors
Brake Levers
Shimano GRX Hydraulic
Cockpit
Stem
FSA ST-OS-185 for SMR system, 6061 alloy, 31.8mm clamp, -6°, length: S: 90mm / M: 100mm / L-XL: 110mm
Handlebar
Fuji, 6061 alloy, 31.8mm clamp, 125mm drop, 25° flare, 4° sweep, width: S: 400mm / M: 420mm / L-XL: 440mm
Grips
Anti-slip silicone
Headset
FSA NO.55R / 1.5"-1.5" / SMR system / ACB bearings
Seat
Saddle
Oval Concepts 300, steel rail
Seatpost
FSA Energy, 6066 alloy micro adjust, 27.2mm diameter, 350mm length
Motor & Battery
Motor
Fazua Evation mid-motor, 250W rated power, 55Nm of torque, 20mph maximum assist
Battery
Fazua Evation 250Wh with charger
Remote
Fazua Evation Satellite remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.5 mm | 1.54 mm | 1.58 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm | 277 mm |
| Front Center | 602 mm | 613 mm | 623 mm | 633 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 73 mm | 69 mm | 66 mm | 63 mm |
| Stack | 557.7 mm | 583.3 mm | 609 mm | 634.7 mm |
| Reach | 381.7 mm | 389 mm | 395.4 mm | 402.5 mm |
| Top Tube Length | 535 mm | 555 mm | 580 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 125 mm | 150 mm | 175 mm | 200 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1028 mm | 1040 mm | 1049 mm | 1060 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 168 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 178 cm | 183 cm | 188 cm |
Model Overview
E-Jari completes the Fuji E E Jari model. There are 4 e-bikes that carry this model name. You can easily view all of the Fuji E E Jari e-bikes models from 2022, here.
Model range prices
Fuji E-Jari EQP 2022 is the most economical model, with a starting price of 4565$. Fuji E-Jari 2022 on the other hand costs 4999$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel e-bikes average price
If you want to purchase a solid Gravel e-bike, it is important to know that the average cost is 3642$. However, you could also get a good Gravel e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 4999$. In conclusion, this e-bike price is 37.26% more expensive than the price of the average Gravel e-bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your e-bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The E-Jari 2022 e-bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The E-Jari has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
E-Jari comes in 4 sizes, that range from 160 cm – 188 cm (5.25 ft – 6.17 ft). In conclusion, it won’t take much to find one that’s right for you.
