Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, FSA -
Suspension Rigid -
Motor Fazua 250W 55Nm mid-drive -
Battery Fazua Evation 250Wh with charger -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL Super-Butted Aluminum, internal cable routing, Fazua compatible, integrated head tube w/ 1 1/2" upper and lower, double water bottle mounts, flat-mount disc system, dropout w/ 12mm replaceable hanger
Suspension Fork
FC-440 Cross carbon monocoque, 12mm thru-axle w/ flat-mount disc tabs, tapered steerer, rack/water bottle mounts
Drivetrain
Rear Derailleur
Shimano GRX RX812 GS
Shift Levers
Shimano GRX Dual Control Hydraulic, 11-speed
Cassette
Shimano HG-5100-11, 11-42T
Crank
FSA CK-746-1/IS, 42T Megatooth, for Fazua
Chain
Shimano HG601-11, HyperGlide-X, 11-speed
Wheels
Rims
WTB HTZ i23 TCS 2.0, 32/32h, 12mm thru-axle cartridge bearing hubs for e-gravel
Tires
WTB Riddler, 700x45c, Dual DNA Compound, Lightweight Tubeless Casing, TCS Aramid Bead, Tan walls
Brakes
Brakes
Shimano GRX Hydraulic, 160/160mm rotors
Brake Levers
Shimano GRX Hydraulic
Cockpit
Stem
FSA ST-OS-185 for SMR system, 6061 alloy, 31.8mm clamp, -6°, length: S: 90mm / M: 100mm / L-XL: 110mm
Handlebar
Fuji, 6061 alloy, 31.8mm clamp, 125mm drop, 25° flare, 4° sweep, width: S: 400mm / M: 420mm / L-XL: 440mm
Grips
Anti-slip silicone
Headset
FSA NO.55R / 1.5"-1.5" / SMR system / ACB bearings
Seat
Saddle
Oval Concepts 300, steel rail
Seatpost
FSA Energy, 6066 alloy micro adjust, 27.2mm diameter, 350mm length
Motor & Battery
Motor
Fazua Evation mid-motor, 250W rated power, 55Nm of torque, 25km/h maximum assist
Battery
Fazua Evation 250Wh with charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.5 mm | 1.54 mm | 1.58 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm | 277 mm |
| Front Center | 602 mm | 613 mm | 623 mm | 633 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 73 mm | 69 mm | 66 mm | 63 mm |
| Stack | 557.7 mm | 583.3 mm | 609 mm | 634.7 mm |
| Reach | 381.7 mm | 389 mm | 395.4 mm | 402.5 mm |
| Top Tube Length | 535 mm | 555 mm | 580 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 125 mm | 150 mm | 175 mm | 200 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1028 mm | 1040 mm | 1049 mm | 1060 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
E-Jari completes the Fuji E E Jari model. There are 5 e-bikes that carry this model name. Take a sneak peek at all Fuji E E Jari e-bikes models from 2023, by clicking here.
Model range prices
Fuji E-Jari 2023 is the cheapest e-bike model and costs 4499$. Fuji E-Jari EQP 2023 is the most expensive one and costs 4552$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel e-bikes
If you want an acceptable Gravel e-bike you should know that the average price is 3642$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2023 for 4499$. In conclusion, this e-bike price is 23.53% higher than the price of the average Gravel e-bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
E-Jari components
Fork material
E-Jari has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Fuji E-Jari 2023, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The E-Jari has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
