Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
157cm - 166cm
XS
150cm - 156cm
SM
154cm - 160cm
MD
157cm - 163cm
LG
160cm - 167cm
XL
164cm - 171cm
XXL
195cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 high-modulus carbon w/ VRTech, integrated head tube w/ 1 1/2" lower, internal cable routing, PF30 BB shell, double water bottle mounts, oversized ETC chainstays, flat-mount disc system, 12mm convertible thru-axle system w/ replaceable hanger & hidden fender eyelet
Suspension Fork
FC-440 carbon monocoque w/ VRTech, tapered carbon steerer, flat-mount disc system, 12mm thru-axle dropout, hidden fender eyelet
Drivetrain
Rear Derailleur
Shimano Ultegra GS
Front Derailleur
Shimano Ultegra, braze-on mount
Shift Levers
Shimano Ultegra Dual Control Hydraulic, 11-speed
Cassette
Shimano HG-700, 11-34T
Crank
Shimano Ultegra, 50/34T
Bottom Bracket
Praxis PF30 conversion bottom bracket
Chain
KMC X11 w/ MissingLink
Pedals
N/A
Wheels
Rims
Oval Concepts 524 Disc, centerlock hubs, 100x12mm & 142x12mm thru axles, 700c 24/28H rims
Tires
Vittoria Zaffiro Pro, 700 x 30, 60tpi, folding
Brakes
Brakes
Shimano Ultegra Hydraulic, 160/160 rotors
Brake Levers
Shimano Ultegra Hydraulic
Cockpit
Stem
Oval Concepts 313, 3D-forged 6061 stem body, +/-7°
Handlebar
Oval Concepts 310 Ergo, 6061 alloy, 31.8mm clamp, 133mm drop, 4° sweep
Headset
FSA, 1 1/8" upper - 1 1/2" lower, integrated
Seat
Saddle
Oval Concepts 544 with pressure relief zone, steel rail
Seatpost
Oval Concepts 905, carbon & alloy, 27.2mm diameter
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.45 mm | 1.53 mm | 1.57 mm | 1.61 mm | 1.62 mm | 1.61 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 579 mm | 582 mm | 585 mm | 579 mm | 588 mm | 608 mm | 628 mm |
| Rake | 52 mm | 52 mm | 52 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 61.7 mm | 58.6 mm | 58.6 mm | 58.7 mm | 58.7 mm | 58.7 mm | 58.7 mm |
| Stack | 498 mm | 523 mm | 549 mm | 574 mm | 594 mm | 617 mm | 637 mm |
| Reach | 361 mm | 360 mm | 360 mm | 365 mm | 368 mm | 381 mm | 395 mm |
| Top Tube Length | 497 mm | 507 mm | 522 mm | 537 mm | 552 mm | 572 mm | 592 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.75 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 100 mm | 125 mm | 150 mm | 170 mm | 190 mm | 215 mm | 235 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 976 mm | 979 mm | 982 mm | 976 mm | 985 mm | 1005 mm | 1025 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 700 | 728 mm | 756 mm | 780 mm | 800 mm | 821 mm | 845 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 150 cm | 154 cm | 157 cm | 160 cm | 164 cm | 195 cm |
| Rider Max Height | 166 cm | 156 cm | 160 cm | 163 cm | 167 cm | 171 cm | 204 cm |
Model Overview
Gran Fondo 1.3 completes the Fuji Gran model. Fuji launched 58 bikes of this model so far. You can easily view all of the Fuji Gran bikes models from 2019, here.
Model range prices
Fuji Gran Fondo Classico 1.3 2019 is the most economical model, with a starting price of 1499$. Fuji Gran Fondo 1.1 2019 on the other hand costs 3999$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2019 for 2799$. Doing a quick comparison, we notice that Gran Fondo 1.3 price is 19.31% higher than the average cost of an Endurance bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Gran Fondo 1.3 components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the Gran Fondo 1.3 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Gran Fondo 1.3 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 7 sizes available for this model. Rider height can be anywhere between 157 cm – 204 cm (5.15 ft – 6.69 ft). In conclusion, it won’t take much to find one that’s right for you.
