Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
150cm - 158cm
XS
156cm - 163cm
SM
160cm - 170cm
MD
168cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
XXL
185cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 high-modulus carbon w/ VRTech, integrated head tube w/ 1 1/2" lower, internal cable routing, PF30 BB shell, double water bottle mounts, oversized ETC chainstays, flat-mount disc system, 12mm convertible thru-axle system w/ replaceable hanger & hidden fender eyelet
Suspension Fork
FC-440 carbon monocoque w/ VRTech, tapered carbon steerer, flat-mount disc system, 12mm thru-axle dropout, hidden fender eyelet
Drivetrain
Rear Derailleur
Shimano Ultegra GS
Front Derailleur
Shimano Ultegra, braze-on mount
Shift Levers
Shimano Ultegra Dual Control Hydraulic, 11-speed
Cassette
Shimano HG-700, 11-34T
Crank
Shimano Ultegra, 50/34T
Bottom Bracket
Praxis PF30 conversion bottom bracket
Chain
KMC X11 w/ MissingLink
Pedals
N/A
Wheels
Rims
Oval Concepts 524 Disc, centerlock hubs, 100x12mm & 142x12mm thru axles, 700c 24/28H rims
Tires
Vittoria Zaffiro Pro, 700 x 30, 60tpi, folding
Brakes
Brakes
Shimano Ultegra Hydraulic, 160/160 rotors
Brake Levers
Shimano Ultegra Hydraulic
Cockpit
Stem
Oval Concepts 313, 3D-forged 6061 stem body, +/-7°
Handlebar
Oval Concepts 310 Ergo, 6061 alloy, 31.8mm clamp, 133mm drop, 4° sweep
Headset
FSA, 1 1/8" upper - 1 1/2" lower, integrated
Seat
Saddle
Oval Concepts 544 with pressure relief zone, steel rail
Seatpost
Oval Concepts 905, carbon & alloy, 27.2mm diameter
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.45 mm | 1.53 mm | 1.57 mm | 1.61 mm | 1.62 mm | 1.61 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 579 mm | 582 mm | 585 mm | 579 mm | 588 mm | 608 mm | 628 mm |
| Rake | 52 mm | 52 mm | 52 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 61.7 mm | 58.6 mm | 58.6 mm | 58.7 mm | 58.7 mm | 58.7 mm | 58.7 mm |
| Stack | 498 mm | 523 mm | 549 mm | 574 mm | 594 mm | 617 mm | 637 mm |
| Reach | 361 mm | 360 mm | 360 mm | 365 mm | 368 mm | 381 mm | 395 mm |
| Top Tube Length | 497 mm | 507 mm | 522 mm | 537 mm | 552 mm | 572 mm | 592 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.75 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 100 mm | 125 mm | 150 mm | 170 mm | 190 mm | 215 mm | 235 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 976 mm | 979 mm | 982 mm | 976 mm | 985 mm | 1005 mm | 1025 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 700 | 728 mm | 756 mm | 780 mm | 800 mm | 821 mm | 845 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 156 cm | 160 cm | 168 cm | 175 cm | 180 cm | 185 cm |
| Rider Max Height | 158 cm | 163 cm | 170 cm | 178 cm | 183 cm | 188 cm | 196 cm |
Model Overview
Gran Fondo 1.3 is a Fuji Gran model. Fuji released 58 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Fuji Gran Fondo Classico 1.3 2020 is the most affordable bike of this model and has a price of 1499$. On the other hand, Fuji Gran Fondo 1.1 2020, is the most expensive and costs 3999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Fuji released this model in 2020, its price was 2799$. Comparing the average cost of an Endurance bike to this one, you will see that Gran Fondo 1.3 price is 19.31% higher.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the Gran Fondo 1.3 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Gran Fondo 1.3 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Fuji Gran Fondo 1.3 bike has 7 sizes, in the range of 150 cm – 196 cm (4.92 ft – 6.43 ft). In conclusion, finding one for you shouldn’t be a problem.
