Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C4 carbon, integrated head tube w/ 1 1/2" lower, internal cable routing, oversized PIIS BB-86 shell, double water bottle mounts
Suspension Fork
FC-440 carbon monocoque w/ tapered carbon steerer & carbon dropout
Drivetrain
Rear Derailleur
Shimano Tiagra, 10-speed
Front Derailleur
Shimano Tiagra, braze-on mount
Shift Levers
Shimano Tiagra STI shifter/brake, 20-speed
Cassette
Shimano Tiagra, 12-28T 10-speed
Crank
FSA Omega alloy compact, 34/50T
Bottom Bracket
Press-Fit BB86 sealed cartridge bearing
Chain
KMC X10, 10-speed
Wheels
Rims
Alex A-CLASS R3.0 alloy
Tires
Hutchinson Nitro, 700x23c, wire bead
Brakes
Brakes
Oval 300 alloy dual pivot
Brake Levers
Shimano Tiagra STI
Cockpit
Stem
Oval 300 3D forged 6061 alloy, 31.8mm, +/-6 degree
Handlebar
Oval 300S double-butted 6061 alloy, 31.8mm
Headset
Oval 1 1/8"U - 1 1/2"L integrated w/ alloy top cover
Seat
Saddle
Oval 300 w/ CrMo rails
Seatpost
Oval 300 alloy 2-bolt, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.345 mm | 1.378 mm | 1.469 mm | 1.563 mm | 1.519 mm | 1.523 mm |
| Front Center | 59 mm | 60 mm | 60 mm | 59 mm | 61 mm | 63 mm |
| Rake | 5.2 mm | 5.2 mm | 5.2 mm | 4.3 mm | 4.3 mm | 4.3 mm |
| Trail | 111 mm | 111 mm | 108 mm | 99 mm | 100 mm | 100 mm |
| Seat Tube Angle | 75 ° | 75 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 550 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 73 ° | 73 ° | 73 ° |
| Bottom Bracket Drop | 6 mm | 6 mm | 6 mm | 6 mm | 6 mm | 6 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Gran Fondo 4.0 belongs to the Fuji Gran model. Fuji released 58 bikes variations of this model so far. Take a sneak peek at all Fuji Gran bikes models from 2012, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Gran Fondo 4.0 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The Gran Fondo 4.0 2012 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Gran Fondo 4.0 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
