Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, FSA -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
150cm - 156cm
SM
154cm - 160cm
MD
157cm - 163cm
LG
160cm - 167cm
XL
164cm - 171cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C15 One-Piece Ultra High Modulus Carbon, Flat Mount Disc, Thru Axle Rear Dropout
Suspension Fork
FC-440 Cross carbon monocoque, 12mm thru-axle w/ flat-mount disc tabs, tapered steerer, rack/water bottle mounts
Drivetrain
Rear Derailleur
Shimano Ultegra RX , long cage
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra, hydraulic disc, 11-speed
Cassette
Shimano Ultegra, 11-34T
Crank
FSA Energy Modular, 46/30T
Bottom Bracket
FSA BB386 EVO sealed-BSA thread
Chain
KMC X11
Pedals
N/A
Wheels
Rims
WTB KOM Light i23 TCS 2.0 , 32/32h, 12mm thru-axle cartridge bearing hubs
Tires
Panaracer Gravelking SK, 700 x 43c
Brakes
Brakes
Shimano Ultegra, hydraulic disc, 160mm rotors
Brake Levers
Shimano Ultegra STI hydraulic disc
Cockpit
Stem
Oval Concepts 707, 3D-forged 6061 stem body, ±7°
Handlebar
Oval Concepts 325, 6061 alloy, 31.8mm clamp, 125mm drop, 25° flare, 4° sweep
Headset
FSA No. 42, 1 1/8" - 1 1/2", integrated cartridge
Seat
Saddle
Oval Concepts X38 with pressure relief zone, cromo rail
Seatpost
Oval Concepts 905, carbon & alloy, 27.2mm diameter
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.49 mm | 1.54 mm | 1.55 mm | 1.58 mm | 1.57 mm |
| Bottom Bracket Height | 280 mm | 282 mm | 282 mm | 282 mm | 284 mm | 284 mm |
| Front Center | 595 mm | 596 mm | 590 mm | 601 mm | 610 mm | 631 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 73 mm | 70 mm | 67 mm | 64 mm | 64 mm | 64 mm |
| Stack | 546 mm | 565 mm | 577 mm | 597 mm | 614 mm | 633 mm |
| Reach | 380 mm | 380 mm | 375 mm | 384 mm | 388 mm | 402 mm |
| Top Tube Length | 530 mm | 540 mm | 550 mm | 565 mm | 580 mm | 600 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 140 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1025 mm | 1027 mm | 1021 mm | 1032 mm | 1042 mm | 1063 mm |
| Bottom Bracket Drop | 69 mm | 67 mm | 67 mm | 67 mm | 65 mm | 65 mm |
| Standover Height | 772 mm | 795 mm | 809 mm | 829 mm | 846 mm | 870 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 154 cm | 157 cm | 160 cm | 164 cm | 186 cm |
| Rider Max Height | 156 cm | 160 cm | 163 cm | 167 cm | 171 cm | 194 cm |
Model Overview
Jari Carbon 1.1 is part of the Fuji Jari model. Fuji released 50 bikes variations of this model so far. Take a sneak peek at all Fuji Jari bikes models from 2019, by clicking here.
Model range prices
Fuji Jari 2.5 2019 is the cheapest bike model and costs 699$. Fuji Jari Carbon 1.1 2019 is the most expensive one and costs 2699$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Fuji Jari Carbon 1.1 price was 2699$. Doing a quick comparison, we notice that Jari Carbon 1.1 price is 9.63% higher than the average cost of a Gravel bike.
Overview of components
Fork material
Jari Carbon 1.1 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Jari Carbon 1.1 2019 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Jari Carbon 1.1 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Fuji Jari Carbon 1.1 bike has 6 sizes, in the range of 150 cm – 194 cm (4.92 ft – 6.36 ft). In short, you can easily find one that suits you.
