Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 120mm -
Fork Fox Factory Float 32
-
Groupset XT -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
D6 high modulus carbon monocoque, semi-integrated oversized 1 1/2" lower head tube, 31.6mm round seat post, water bottle mount
Suspension Fork
Fox 32 Float Factory Fit w/ remote lockout, 120mm travel
Rear Shock
Fox Float RP23 Performance
Drivetrain
Rear Derailleur
Shimano Deore XT SGS Shadow top normal, 10-speed
Front Derailleur
Shimano Deore XT, 34.9mm
Shift Levers
Shimano Deore XT Rapid Fire, 20-speed
Cassette
Shimano SLX, 11-36T 10-speed
Crank
Shimano Deore XT Hollow Tech II w/ integrated spindle, 28/40T
Bottom Bracket
Shimano Press-Fit
Chain
KMC, 10-speed
Pedals
N/A
Wheels
Rims
Deore XT 32H hubs, WTB Laser TCS XC rims
Tires
Continental Race King 26x2.2" folding or Hutchinson Cobra Air Light 26x2.25" folding
Brakes
Brakes
Shimano Deore XT hydraulic disc, 180/160mm centerlock rotor
Brake Levers
Shimano Deore XT hydraulic
Cockpit
Stem
Oval M600 alloy reverse bolt technology, 31.8mm
Handlebar
Oval M600 alloy riser bar, 15mm rise, 9° sweep, 31.8mm, 680mm wide
Headset
Oval sealed bearing 1 1/8" - 1 1/2"
Seat
Saddle
Oval M600 w/ titanium rails
Seatpost
Oval M600, 31.6x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG |
|---|---|---|---|---|
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Top Tube Length | 556 mm | 586 mm | 617 mm | 647 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 605 mm | 660 mm | 482 mm | 533 mm |
| Head Tube Angle | 71 ° | 71 ° | 70 ° | 70 ° |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1039 mm | 1069 mm | 1111 mm | 1141 mm |
| Bottom Bracket Drop | 4 mm | 4 mm | 4 mm | 4 mm |
| Standover Height | 751 mm | 771 mm | 804 mm | 811 mm |
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
Mt. Fuji 1.0 is part of the Fuji Mt model. There are 26 bikes that carry this model name. You can easily view all of the Fuji Mt bikes models from 2012, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Mt. Fuji 1.0 components
Fork
The Fox Factory Float 32 is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the Mt. Fuji 1.0 bike is equipped with the 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Mt. Fuji 1.0 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
