Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 120mm -
Fork Fox Float 32
-
Groupset SLX -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 super-light carbon monocoque, semi-integrated oversized 1.5" lower head tube, 31.6mm round seat post, water bottle mount
Suspension Fork
Fox 32 FLOAT Evolution CTD w/ 15mm thru axle, tapered alloy steerer, 120mm travel
Rear Shock
Fox Float Evolution CTD
Drivetrain
Rear Derailleur
Shimano SLX, M675 SGS Shadow Plus top normal, 10-speed
Front Derailleur
Shimano SLX, M676, direct°€mount
Shift Levers
Shimano SLX, M670 Rapid Fire, 20/30-speed w/ Inspec
Cassette
Shimano Deore HG62, 11-36T, 10-speed
Crank
Shimano SLX, M675 hollow Tech II w/ integrated spindle, 40/28T
Bottom Bracket
Shimano BB91 press-fit
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Shimano SLX M678 32H Center Lock disc hubs, Sun Inferno 23
Tires
Schwalbe Nobby Nic, Evo 26" x 2.25" folding, 67 tpi
Brakes
Brakes
Shimano SLX M675, hydraulic disc, 180mm/160mm rotor
Brake Levers
Shimano SLX M675 hydraulic
Cockpit
Stem
Oval M213, 3D-forged alloy, 31.8mm clamp diameter, 6° rise
Handlebar
Oval M200, alloy riser bar, 9° sweep, 31.8mm diameter, 710mm wide, 15mm rise
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval M400 w/ satin steel rails
Seatpost
Oval M200, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.4 mm | 1.31 mm | 1.24 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm |
| Stack | 571.7 mm | 571.7 mm | 571.7 mm | 571.7 mm |
| Reach | 377.9 mm | 407.4 mm | 437 mm | 462.2 mm |
| Top Tube Length | 554 mm | 583.8 mm | 608.8 mm | 639 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 482 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 125 mm | 125 mm | 125 mm | 125 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1053 mm | 1083 mm | 1108 mm | 1139 mm |
| Standover Height | 787 mm | 801 mm | 816 mm | 823 mm |
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
Mt Fuji 1.3 D belongs to the Fuji Mt model. Fuji launched 26 bikes of this model so far. Take a sneak peek at all Fuji Mt bikes models from 2013, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Mt Fuji 1.3 D components
Fork
The Mt Fuji 1.3 D comes factory-installed with the Fox Float 32 fork. This has a travel range of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
When leaving the production line, the Mt Fuji 1.3 D model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Mt Fuji 1.3 D is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
