Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Fork Fox Factory Float 32 -
Groupset XTR -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
D6 high modulus carbon monocoque, semi-integrated oversized 1 1/2" lower head tube, 31.6mm round seat post, water bottle mount
Suspension Fork
Fox 32 Float Factory Fit w/ remote lockout, 120mm travel
Rear Shock
Fox Float RP23 Factory
Drivetrain
Rear Derailleur
Shimano XTR SGS Shadow top normal, 10-speed
Front Derailleur
Shimano XTR, 34.9mm
Shift Levers
Shimano XTR Rapid Fire, 20-speed
Cassette
Shimano XTR, 11-36T 10-speed
Crank
Shimano XTR Hollow Tech II w/ integrated spindle, 30/42T
Bottom Bracket
Shimano Press-Fit
Chain
Shimano XTR, 10-speed
Pedals
N/A
Wheels
Rims
WTB Stryker TCS Cross Country Race
Tires
WTB Bronson, 26x2.1" folding
Brakes
Brakes
Shimano XTR hydraulic disc, 180/160mm centerlock rotor
Brake Levers
Shimano XTR hydraulic
Cockpit
Stem
Oval M800 carbon matrix reverse bolt technology, 31.8mm
Handlebar
Oval M800 carbon riser bar, 15mm rise, 9° sweep, 31.8mm, 685mm wide
Headset
Oval sealed bearing 1 1/8" - 1 1/2"
Seat
Saddle
Oval M800 w/ carbon rails
Seatpost
Oval M800 carbon, 31.6x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG |
|---|---|---|---|---|
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Top Tube Length | 556 mm | 586 mm | 617 mm | 647 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 605 mm | 660 mm | 482 mm | 533 mm |
| Head Tube Angle | 71 ° | 71 ° | 70 ° | 70 ° |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1039 mm | 1069 mm | 1111 mm | 1141 mm |
| Standover Height | 751 mm | 771 mm | 804 mm | 811 mm |
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
Mt. Fuji LTD SL is part of the Fuji Mt model. Fuji released 26 bikes variations of this model so far. You can get a glimpse at all models from 2012, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Mt. Fuji LTD SL components
Fork
The Fox Factory Float 32 is included from the factory. It has a travel distance of mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When it comes to wheels, the Mt. Fuji LTD SL bike is equipped with the 26″ aluminum model. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Mt. Fuji LTD SL has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
