Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Acera, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A1-SL Aluminum with PowerCurve down tube, Tri shaped top tube, Oversized seat tube and integrated head tube, double water bottle mounts
Suspension Fork
SR Suntour XCT, 100mm Travel w/Mechanical LO
Rear Shock
none
Drivetrain
Rear Derailleur
Shimano Acera SGS 8sp
Front Derailleur
Shimano TX-50, 34.9mm
Shift Levers
Shimano SL-M310 EZ Fire shifter/brake, 24-speed
Cassette
Shimano Cassette, 11-34T 8sp
Crank
Shimano M171, 24/34/42T with Chainguard
Bottom Bracket
Sealed Cartridge Bearing ST
Chain
KMC Z-72
Pedals
FPD w/Boron Axle
Wheels
Rims
Fuji Disc Mount hubs, Fuji Double Wall Alloy / CMC Sidewalls rims
Tires
Kenda K-837F/K-848R ATB, 26 x 2.1" Wire Bead
Brakes
Brakes
Tektro Draco Hydraulic Disc, 180/160mm rotor
Brake Levers
Tektro Draco Hydraulic Disc Brake Lever
Cockpit
Stem
Fuji Forged Alloy w/removable faceplate
Handlebar
Fuji Riser 20 Alloy Riser Bar
Headset
Fuji Custom 1 1/8" Press Fit Integrated, 30mm spacers
Seat
Saddle
Fuji Sport MTB w/ steel rail
Seatpost
Fuji Alloy micro-adjust, 350x31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 296 mm | 296 mm | 296 mm | 296 mm | 296 mm |
| Top Tube Length | 543 mm | 578 mm | 598 mm | 628 mm | 648 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 482 mm | 533 mm | 584 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1027 mm | 1062 mm | 1083 mm | 1113 mm | 1134 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Standover Height | 741 mm | 766 mm | 793 mm | 821 mm | 851 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Nevada 2.0 LE (Euro) belongs to the Fuji Nevada model. Fuji launched 241 bikes of this model so far. Take a sneak peek at all Fuji Nevada bikes models from 2011, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
The fork installed on this bike is the SunTour XCT model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Nevada 2.0 LE (Euro) are the 26″ aluminum type. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Nevada 2.0 LE (Euro) comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Fuji Nevada 2.0 LE (Euro) bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
