Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 80mm -
Fork SunTour XCM HLO
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NEW Fuji Altair 1 aluminum with PowerCurve down tube, Tri shaped top tube, Oversized seat tube and integrated head tube, double water bottle mounts
Suspension Fork
SR Suntour XCM-HLO w/Hydraulic LO & 80mm Travel
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano Acera, 34.9mm
Shift Levers
Shimano Acera ST-M360 EZ Fire shifter/brake, 24-speed
Cassette
Shimano HG-30, 11-34T 8-speed
Crank
Shimano FC-M361 Forged Alloy , 22/32/42T with Chaingaurd
Bottom Bracket
Sealed Cartridge Bearing ST
Chain
KMC Z-72, 8sp
Pedals
FPD ATB w/steel cage
Wheels
Front Hub
Shimano HB-RM60 , 32H w/QR
Rear Hub
Shimano FH-RM60 cassette, 32H w/QR
Rims
Jalco ATB-220 Double Wall Aluminum /CNC Sidewalls
Spokes
14G Stainless Steel
Tires
Kenda K-837F/K-848R ATB, 26 x 2.1"
Brakes
Brakes
Tektro 837AL Forged Alloy, linear pull
Brake Levers
Shimano Acera ST-M360 Forged Alloy
Cockpit
Stem
Fuji Forged Aluminum w/removable faceplate
Handlebar
Fuji Riser 20 aluminum
Headset
V.P. 1 1/8" Press Fit Integrated, 30mm spacers
Seat
Saddle
Fuji Race MTB
Seatpost
Fuji Aluminum micro-adjust, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 296 mm | 296 mm | 296 mm | 296 mm | 296 mm |
| Front Center | 606 mm | 642 mm | 662 mm | 693 mm | 713 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 543 mm | 578 mm | 598 mm | 628 mm | 648 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 482 mm | 533 mm | 584 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 150 mm | 165 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1027 mm | 1062 mm | 1083 mm | 1113 mm | 1134 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 34 mm | 34 mm | 34 mm |
| Standover Height | 741 mm | 766 mm | 793 mm | 821 mm | 851 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
NEVADA 2.0-USA completes the Fuji Nevada model. There are 241 bikes that carry this model name. Check out the entire range from 2010 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
NEVADA 2.0-USA weighs 14.13 kg (31.15 lbs) and is considerably heavier than the average. To sum up, it’s 13.95% heavier than the average weight of Crosscountry bikes.
Overview of components
Fork
The fork installed on this bike is the SunTour XCM HLO model. The travel on this model is 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the NEVADA 2.0-USA model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
