Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset X4, microSHIFT -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 163cm
SM
160cm - 170cm
MD
168cm - 178cm
LG
175cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle
Suspension Fork
SR Suntour SF19-XCT30-HLO-DS-27.5, hydraulic lockout, 100mm
Drivetrain
Rear Derailleur
SRAM X4
Front Derailleur
Microshift FD-M20
Shift Levers
SRAM X4, 3 x 8-speed
Cassette
Sunrace CSM66, 11-34T
Crank
Prowheel, 42/34/24T
Bottom Bracket
Sealed cartridge bearing
Chain
KMC HV700
Pedals
Resin platform
Wheels
Rims
WTB SX19 rims 32H, Formula DC-20 front, DC-22 rear hubs, black spokes
Tires
WTB Ranger Comp, 27.5" x 2.25", 27tpi
Brakes
Brakes
Tektro HD-M275, 180/160mm rotors
Brake Levers
Tektro HD-M275
Cockpit
Stem
Fuji, forged aluminum, +/-6°
Handlebar
Fuji riser bar, alloy, 15mm rise, 710mm
Grips
Fuji Performance Grip
Headset
1 1/8" sealed bearings
Seat
Saddle
Fuji Performance Saddle
Seatpost
Fuji, alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.52 mm | 1.48 mm | 1.41 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 632 mm | 651 mm | 673 mm | 701 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 88 mm | 88 mm | 88 mm | 88 mm |
| Stack | 591 mm | 595 mm | 605 mm | 614 mm |
| Reach | 375 mm | 392 mm | 410 mm | 435 mm |
| Top Tube Length | 557 mm | 576 mm | 596 mm | 624 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 310 mm | 370 mm | 420 mm | 470 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1063 mm | 1082 mm | 1104 mm | 1132 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 732 mm | 762 mm | 790 mm | 818 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 160 cm | 168 cm | 175 cm |
| Rider Max Height | 163 cm | 170 cm | 178 cm | 183 cm |
Model Overview
Nevada 27.5 1.7 SRAM is part of the Fuji Nevada model. Fuji released 241 bikes variations of this model so far. Take a sneak peek at all Fuji Nevada bikes models from 2022, by clicking here.
Model range prices
Fuji Nevada 26 1.9 V 2022 is the most economical model, with a starting price of 562$. Fuji Nevada 29 1.0 LTD 2022 on the other hand costs 1167$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Fuji released this model in 2022, its price was 849$. In conclusion, this bike price is 124.38% lower than the price of the average Crosscountry bike.
Nevada 27.5 1.7 SRAM components
Fork
Fuji Nevada 27.5 1.7 SRAM 2022 bike is equipped with the Suntour XCT fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The Nevada 27.5 1.7 SRAM 2022 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 183 cm (4.99 ft – 6 ft). In conclusion, it won’t take much to find one that’s right for you.
