Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle
Suspension Fork
SR Suntour SF19-XCE-DS-27.5, 100mm
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano Tourney
Shift Levers
Shimano Altus, Rapid Fire, 3 x 7-speed
Cassette
Shimano TZ500 freewheel, 14-34T
Crank
Prowheel, 42/34/24T
Bottom Bracket
Sealed cartridge bearing
Chain
KMC HV500
Pedals
Resin platform
Wheels
Rims
WTB SX19 rims 32H, Formula DC-20 front, DC-31 rear hub, black spokes
Tires
WTB Ranger Comp, 27.5" x 2.25", 27tpi
Brakes
Brakes
Tektro M275, 160mm rotors
Brake Levers
Tektro M275
Cockpit
Stem
Fuji, forged aluminum, +/-6°
Handlebar
Fuji riser bar, alloy, 15mm rise, 710mm
Grips
Fuji Performance Grip
Headset
1 1/8" sealed bearings
Seat
Saddle
Fuji Performance Saddle
Seatpost
Fuji, alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.52 mm | 1.48 mm |
| Front Center | 632 mm | 651 mm | 673 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Stack | 591 mm | 595 mm | 605 mm |
| Reach | 375 mm | 392 mm | 410 mm |
| Top Tube Length | 557 mm | 576 mm | 596 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 310 mm | 370 mm | 420 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1063 mm | 1082 mm | 1104 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Standover Height | 732 mm | 762 mm | 790 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
Nevada 27.5 4.0 LTD is part of the Fuji Nevada model. Fuji released 241 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Fuji Nevada 26 1.9 V 2022 is the cheapest bike model and costs 562$. Fuji Nevada 29 1.0 LTD 2022 is the most expensive one and costs 1167$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Mountain bikes average price
If you want to purchase a solid Mountain bike, it is important to know that the average cost is 616$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Mountain bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Fuji released this model in 2022, its price was 742$. Comparing this to the average Mountain bike price, we see that the price is 20.45% more expensive.
Nevada 27.5 4.0 LTD components
Fork
Fuji Nevada 27.5 4.0 LTD 2022 bike is equipped with the Suntour XCE fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the Nevada 27.5 4.0 LTD bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Nevada 27.5 4.0 LTD comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 151 cm – 179 cm (4.95 ft – 5.87 ft). In short, it won’t be difficult to find the right one for you.
