Fuji Nevada 29 1.0 LTD 2023
2023 Youth
Estimate price |
1,261$
Weight | 14.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle
Suspension Fork
SR Suntour SF14-XCR-AIR-LOR-DS-29, 100mm
Drivetrain
Rear Derailleur
Shimano Deore
Shift Levers
Shimano Deore, 1 x 12-speed
Cassette
Shimano Deore, 10-51T
Crank
Shimano Deore, 32T
Bottom Bracket
Shimano, threaded
Chain
KMC X12
Pedals
Resin platform
Wheels
Rims
WTB SX19 rims 32H, Shimano HB-TX505 front, Shimano MT401 rear hub, stainless black spokes
Tires
WTB Ranger Comp, 29" x 2.25", 27tpi
Brakes
Brakes
Shimano MT200, 180/160mm rotors
Brake Levers
Shimano MT200
Cockpit
Stem
Fuji, forged aluminum, +/-6°
Handlebar
Fuji flat bar, alloy, 710mm
Grips
Fuji Performance Grip Lock On
Headset
1 1/8" sealed bearings
Seat
Saddle
WTB Volt Sport
Seatpost
Fuji, alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.4 mm | 1.38 mm | 1.35 mm |
| Front Center | 690 mm | 715 mm | 733 mm | 752 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Stack | 624 mm | 628.5 mm | 638 mm | 647 mm |
| Reach | 424 mm | 448 mm | 462 mm | 478 mm |
| Top Tube Length | 614 mm | 639 mm | 656 mm | 675 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 470 mm | 520 mm | 560 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1137 mm | 1163 mm | 1180 mm | 1200 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 812 mm | 837 mm | 865 mm | 889 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Nevada 29 1.0 LTD completes the Fuji Nevada model. There are 241 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Fuji Nevada 27.5 1.9 2023 is the cheapest bike model and costs 413$. Fuji Nevada 29 1.0 LTD 2023 is the most expensive one and costs 1167$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Mountain bikes average price
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, you could also get a good Mountain bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Fuji released this model in 2023, its price was 1167$. In conclusion, this bike price is 89.45% more expensive than the price of the average Mountain bike.
Mountain bikes average weight
If we make a quick analysis of the average weight of a Mountain bike, we get 11.4 kg (25.13 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Fuji Nevada 29 1.0 LTD it’s weighing 14.3 kg (31.53 lbs). At this weight, is much heavier than average. To sum up, it’s 25.44% heavier than the average weight of Mountain bikes.
Nevada 29 1.0 LTD components
Fork
This bike has the Suntour XCR Air fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Nevada 29 1.0 LTD are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Nevada 29 1.0 LTD has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
