Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset Deore, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
168cm - 176cm
MD
174cm - 180cm
LG
178cm - 185cm
XL
173cm - 193cm
XXL
190cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle
Suspension Fork
SR Suntour SF15-XCM-HLO-DS-29, hydraulic lockout, 100mm
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus, Rapid Fire, 3 x 9-speed
Cassette
Shimano HG200-9, 11-36T
Crank
Shimano Acera, 40/30/22T
Bottom Bracket
Sealed cartridge bearing
Chain
KMC Z9
Pedals
Resin platform
Wheels
Rims
WTB SX19 rims 32H, Shimano HB-TX505 front, FH-TX505 rear hub, stainless black spokes
Tires
WTB Ranger Comp, 29" x 2.25", 27tpi
Brakes
Brakes
Shimano MT200, 180/160mm rotors
Brake Levers
Shimano MT200
Cockpit
Stem
Oval Concepts 313, alloy, +/-7°
Handlebar
Oval Concepts flat bar, alloy, 710mm
Grips
Fuji Performance Grip
Headset
1 1/8" sealed bearings
Seat
Saddle
WTB Volt Sport
Seatpost
Oval Concepts, alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.57 mm | 1.49 mm | 1.46 mm | 1.42 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 646 mm | 667 mm | 692 mm | 707 mm | 727 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 87 mm | 87 mm | 87 mm | 87 mm | 87 mm |
| Stack | 621.9 mm | 631.3 mm | 636 mm | 640.7 mm | 650.1 mm |
| Reach | 386.1 mm | 403.2 mm | 426.7 mm | 440.3 mm | 457.4 mm |
| Top Tube Length | 577 mm | 597 mm | 622 mm | 637 mm | 657 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 430 mm | 483 mm | 530 mm | 580 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 115 mm | 120 mm | 130 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1071 mm | 1092 mm | 1117 mm | 1132 mm | 1152 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 649 mm | 694 mm | 724 mm | 755 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 168 cm | 174 cm | 178 cm | 173 cm | 190 cm |
| Rider Max Height | 176 cm | 180 cm | 185 cm | 193 cm | 198 cm |
About this model
Nevada 29 1.5 completes the Fuji Nevada model. Fuji launched 241 bikes of this model so far. You can easily view all of the Fuji Nevada bikes models from 2020, here.
Model range prices
Fuji Nevada 27.5 1.9 2020 is the most affordable bike of this model and has a price of 499$. On the other hand, Fuji Nevada 29 1.1 2020, is the most expensive and costs 1199$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 849$. If we compare this with the average Crosscountry bike cost we notice that the price is 124.38% smaller.
Nevada 29 1.5 components
Fork
The fork installed on this bike is the SunTour XCM HLO model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Nevada 29 1.5 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Nevada 29 1.5 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 168 cm – 198 cm (5.51 ft – 6.5 ft). In short, you can easily find one that suits you.
