Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy w/ PowerCurve down tube, oversized seat tube
Suspension Fork
SR Suntour SF14-XCT-MLO w/ 100mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Acera, M360 SGS, 8-speed
Front Derailleur
Shimano Altus, M310, 34.9mm
Shift Levers
Shimano SL-M310 Rapid Fire, 8-speed
Cassette
Shimano HG31, 11-34T, 8-speed
Crank
SR Suntour XCT, 42/32/22T
Bottom Bracket
FSA square taper w/ sealed cartridge bearing
Chain
KMC, HV700, 8-speed
Pedals
Plastic platform
Wheels
Rims
Formula DC-20 front / DC-22 rear, 32H hubs w/ Vera Terra DPD18 rims
Tires
Vera Eos, 29" x 2.1", 30 tpi
Brakes
Brakes
Promax Decipher, hydraulic disc, 180mm/160mm rotor
Brake Levers
Promax Decipher, hydraulic disc
Cockpit
Stem
Oval, melt-forged alloy, 31.8mm clamp diameter, 10° rise
Handlebar
Oval M100, alloy bar, 9° sweep, 31.8mm diameter, 710mm wide
Headset
FSA 1 1/8" semi-integrated, caged bearings
Seat
Saddle
Oval Mountain w/ satin steel rails
Seatpost
Oval, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.72 mm | 1.69 mm | 1.59 mm | 1.55 mm | 1.56 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 624 mm | 639 mm | 659 mm | 674 mm | 725 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 80 mm | 74 mm | 78 mm | 80 mm | 44 mm |
| Stack | 637.8 mm | 640.2 mm | 640.2 mm | 647.2 mm | 666.1 mm |
| Reach | 370.6 mm | 379.1 mm | 402.5 mm | 417.5 mm | 426.3 mm |
| Top Tube Length | 573 mm | 588 mm | 608 mm | 623 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 482.6 mm | 533 mm | 584 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 130 mm | 130 mm | 130 mm | 150 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1059 mm | 1075 mm | 1095 mm | 1110 mm | 1161 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 779 mm | 807 mm | 829 mm | 854 mm | 887 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Nevada 29 1.6 completes the Fuji Nevada model. Fuji released 241 bikes variations of this model so far. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Crosscountry bikes average weight
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 15 kg (33.07 lbs), the Nevada 29 1.6 model is much heavier than average. In other words, this model is 20.97% heavier than the average Crosscountry bike.
Overview of components
Fork
Fuji Nevada 29 1.6 2014 bike is equipped with the SunTour XCT fork, and has 100mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Nevada 29 1.6 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Nevada 29 1.6 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
