Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 29" -
Travel Front 63mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Elios 1 steel w/ PowerCurve down tube, tri-shaped top tube, oversized seat tube
Suspension Fork
SR Suntour SF13-M3020 w/ 63mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney, TX35, 7-speed
Front Derailleur
Shimano Tourney, TZ31, 31.8mm
Shift Levers
Shimano EF40 EZ Fire, 7-speed
Cassette
SunRun freewheel, 13-34T, 7-speed
Crank
Vuelta alloy, 44/32/22T w/ chainguard
Bottom Bracket
FSA square taper w/ sealed cartridge bearing
Chain
Fixed Star, FG-50, 7-speed
Pedals
Plastic platform
Wheels
Rims
Formula FM21 front / FM31 rear, alloy 32H hubs, Vera Terra SPM16
Tires
Vera Eos, 29" x 2.1", 30 tpi
Brakes
Brakes
Tektro alloy, linear pull
Brake Levers
Shimano EF40 2-finger brake/shifter combo
Cockpit
Stem
Fuji, melt-forged alloy, 25.4mm clamp diameter, 20° rise
Handlebar
Fuji steel rise bar, 6° degree sweep, 25.4mm diameter, 660mm wide, 30mm rise
Headset
FSA 1 1/8" caged bearings+E596
Seat
Saddle
Oval Mountain w/ satin steel rails
Seatpost
Fuji, alloy double-bolt micro-adjust, 28.6x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.71 mm | 1.69 mm | 1.61 mm | 1.54 mm | 1.56 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 613 mm | 628 mm | 648 mm | 663 mm | 677 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 81 mm | 81 mm | 79 mm | 81 mm | 81 mm |
| Stack | 625.8 mm | 635.2 mm | 635.2 mm | 635.2 mm | 654.1 mm |
| Reach | 364.9 mm | 376.6 mm | 394.6 mm | 411.6 mm | 419.9 mm |
| Top Tube Length | 573 mm | 588 mm | 608 mm | 623 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 482 mm | 533 mm | 584 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 105 mm | 115 mm | 115 mm | 115 mm | 135 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1049 mm | 1063 mm | 1083 mm | 1098 mm | 1113 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 779 mm | 807 mm | 829 mm | 854 mm | 887 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
Nevada 29 2.1 completes the Fuji Nevada model. 241 bikes variations carry this model name so far. Take a sneak peek at all Fuji Nevada bikes models from 2013, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Nevada 29 2.1 components
Fork
This bike has the SunTour fork installed. The fork’s travel is 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The Nevada 29 2.1 2013 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Nevada 29 2.1 has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
