Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle
Suspension Fork
SR Suntour SF19-XCT30-HLO-DS-29, 100mm
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus, Rapid Fire, 3 x 9-speed
Cassette
Shimano HG201-9, 11-36T
Crank
Shimano Altus, 40/30/22T
Bottom Bracket
Sealed cartridge bearing
Chain
KMC Z9
Pedals
Resin platform
Wheels
Rims
WTB SX19 rims 32H, Formula DC-20 front, DC-22 rear hub, black spokes
Tires
WTB Ranger Comp, 29" x 2.25", 27tpi
Brakes
Brakes
Tektro M275, 180/160mm rotors
Brake Levers
Tektro M275
Cockpit
Stem
Fuji, forged aluminum, +/-6°
Handlebar
Fuji flat bar, alloy, 710mm
Grips
Fuji Performance Grip
Headset
1 1/8" sealed bearings
Seat
Saddle
Fuji Performance Saddle
Seatpost
Fuji, alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.4 mm | 1.38 mm | 1.35 mm |
| Front Center | 690 mm | 715 mm | 733 mm | 752 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Stack | 624 mm | 628.5 mm | 638 mm | 647 mm |
| Reach | 424 mm | 448 mm | 462 mm | 478 mm |
| Top Tube Length | 614 mm | 639 mm | 656 mm | 675 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 470 mm | 520 mm | 560 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1137 mm | 1163 mm | 1180 mm | 1200 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 812 mm | 837 mm | 865 mm | 889 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
Nevada 29 3.0 LTD belongs to the Fuji Nevada model. 241 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Fuji Nevada 26 1.9 V 2022 is the cheapest bike model and costs 562$. Fuji Nevada 29 1.0 LTD 2022 is the most expensive one and costs 1167$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Mountain bikes average price
If you want an acceptable Mountain bike you should know that the average price is 616$. However, this doesn’t mean that if you spend less money on a Mountain bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Fuji released this model in 2022, its price was 848$. Comparing this to the average Mountain bike price, we see that the price is 37.66% higher.
Nevada 29 3.0 LTD components
Fork
The fork installed on this bike is the Suntour XCT model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on Nevada 29 3.0 LTD are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
