Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 50mm -
Fork SunTour
-
Groupset Altus, Suntour SR -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Altair 1 aluminum with PowerDiamond down tube, top tube/seat tube gusset, down tube gusset, double water bottle mounts
Suspension Fork
SR SunTour M-2000 suspension fork, 50mm travel
Drivetrain
Rear Derailleur
Shimano Altus MegaRange
Front Derailleur
SR SunTour XR-05, 31.8mm
Shift Levers
Shimano Altus EZ-Fire brake/shifter, 24-speed
Cassette
SunRace freewheel,13/32T 8-speed
Crank
SR SunTour XCC-100 forged Al, 28/38/48T with chainguard
Bottom Bracket
Sealed Cartridge
Chain
KMC Z-72
Pedals
Wellgo water resistant resin ATB, Toe Clip Attachable
Wheels
Front Hub
Formula oversized sealed Al, 36H w/QR
Rear Hub
Formula oversized sealed Al cassette, 36H w/QR
Rims
VP-20 aluminum
Spokes
Stainless Steel, 14 gauge
Tires
CST ATB, 26 X 1.95"
Brakes
Brakes
ProMax aluminum linear pull
Brake Levers
Shimano Altus EZ-Fire brake/shifter
Cockpit
Stem
Fuji forged aluminum w/removable faceplate
Handlebar
Fuji riser ATB
Headset
Ritchey AheadSet threadless w/30mm spacers
Seat
Saddle
Fuji MTB, Men's/Ladies specific
Seatpost
Fuji Aluminum micro adjust 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" | 15" | LG | LG | LG | LG | 17" | 19" | 20.5" |
|---|---|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 302 mm | 302 mm | 302 mm | 302 mm | 302 mm | 302 mm | 302 mm | 302 mm | 302 mm |
| Front Center | 579 mm | 579 mm | 581 mm | 581 mm | 581 mm | 602 mm | 610 mm | 625 mm | 642 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 517.2 mm | 517.2 mm | 517.2 mm | 517.2 mm | 517.2 mm | 537.2 mm | 547.1 mm | 562.1 mm | 577.1 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 381 mm | mm | mm | mm | mm | 432 mm | 483 mm | 521 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 90 mm | 90 mm | 115 mm | 115 mm | 115 mm | 140 mm | 100 mm | 150 mm | 140 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1005 mm | 1005 mm | 1006 mm | 1006 mm | 1006 mm | 1028 mm | 1035 mm | 1051 mm | 1067 mm |
| Bottom Bracket Drop | 31 mm | 31 mm | 31 mm | 31 mm | 31 mm | 31 mm | 31 mm | 31 mm | 31 mm |
| Standover Height | 715 mm | 715 mm | 666 mm | 666 mm | 675 mm | 687 mm | 743 mm | 774 mm | 803 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
Model Overview
Nevada 4.0 completes the Fuji Nevada model. Fuji launched 241 bikes of this model so far. Take a sneak peek at all Fuji Nevada bikes models from 2006, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Crosscountry bikes average weight
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 13.8 kg (30.42 lbs), Fuji bike is considerably heavier than average. In conclusion, the average Crosscountry bike weighs 11.29% less than Nevada 4.0.
Nevada 4.0 components
Fork
This bike has the SunTour fork installed. The fork’s travel is 50mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The Nevada 4.0 2006 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Nevada 4.0 comes with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
