Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset 105, Tiagra -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A1-SL Compact Aluminum with Power Diamond shape down tube, Double water bottle mounts
Suspension Fork
FC-770 Bonded Carbon Integrated w/1 1/8" Alloy Steerer
Drivetrain
Rear Derailleur
Shimano 105, 10sp
Front Derailleur
Shimano Tiagra, 31.8mm clamp
Shift Levers
Shimano Tiagra STI shifter/brake, 27-speed Flight Deck compatible
Cassette
Shimano Tiagra, 12-25T 9sp
Crank
FSA Vero Forged Alloy, 30/39/50T Chainrings
Bottom Bracket
Sealed Cartridge Bearing ST
Chain
KMC Z-99, 9sp
Wheels
Rims
Alex AKX R1.0 Alloy Clincher Wheelset, 700c
Tires
Kenda K-152, 700x25c, Wire bead
Brakes
Brakes
Tektro R-350 Forged Alloy, dual pivot
Brake Levers
Shimano Tiagra STI
Cockpit
Stem
Fuji Adjustable Road
Handlebar
Fuji Alloy Anatomical Drops
Headset
V.P. 1 1/8" Standard Semi Cartridge w/Convex Alloy spacer
Seat
Saddle
Fuji Road Sport Anatomical
Seatpost
Fuji Comp MicroAdjust Forged Alloy, 350x27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.42 mm | 1.5 mm | 1.46 mm | 1.5 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 263 mm | 263 mm |
| Front Center | 584 mm | 587 mm | 584 mm | 595 mm | 619 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 68 mm | 61 mm | 58 mm | 56 mm | 56 mm |
| Stack | 515 mm | 538.6 mm | 568.9 mm | 575.5 mm | 610 mm |
| Reach | 382.5 mm | 378.8 mm | 379 mm | 393 mm | 407 mm |
| Top Tube Length | 513 mm | 533 mm | 548 mm | 568 mm | 593 mm |
| Seat Tube Angle | 76 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 105 mm | 126 mm | 156 mm | 161 mm | 197 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 996 mm | 999 mm | 997 mm | 1007 mm | 1032 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Standover Height | 713 mm | 742 mm | 776 mm | 798 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Newest 1.0 is a Fuji Newest model. There are 46 bikes that carry this model name. You can get a glimpse at all models from 2011, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for General Road bikes
Our math shows that the average cost of a dependable General Road bike is 1915$. However, even if your budget is less than the average, you might still be able to get a top-quality General Road bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
General Road bikes average weight
If we make a quick analysis of the average weight of a General Road bike, we get 9 kg (19.84 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Newest 1.0 weighs 10.8 kg (23.81 lbs) and is much heavier than the average. To sum up, it’s 20% heavier than the average weight of General Road bikes.
Newest 1.0 components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Newest 1.0 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Newest 1.0 has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
Newest 1.0 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
