Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A1-SL compact alloy w/ hydroformed top tube & down tube, double water bottle mounts
Suspension Fork
FC-770 carbon integrated w/1 1/8" alloy steerer
Drivetrain
Rear Derailleur
Shimano Tiagra, 10-speed
Front Derailleur
Shimano Tiagra, band type 31.8mm
Shift Levers
Shimano Tiagra STI shifter/brake, 30-speed Flight Deck compatible
Cassette
Shimano Tiagra, 11-25T 10-speed
Crank
FSA Vero forged alloy, 30/39/50T
Bottom Bracket
Sealed cartridge bearing
Chain
KMC X10, 10-speed
Wheels
Rims
Fuji alloy 32H hubs w/ Fuji alloy CNC sidewalls
Tires
Kenda K-152, 700x25c
Brakes
Brakes
Tektro R-325 dual pivot
Brake Levers
Shimano Tiagra STI
Cockpit
Stem
Fuji CGC alloy road, 31.8mm
Handlebar
Fuji CGC alloy w/ shallow drops
Headset
Fuji 1 1/8" steel ball bearings w/ alloy top cover
Seat
Saddle
Fuji Road-sport anatomical
Seatpost
Fuji CGC Alloy, 350x27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM/MD | MD | MD/LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.403 mm | 1.499 mm | 1.464 mm | 1.498 mm |
| Front Center | 58 mm | 59 mm | 58 mm | 59 mm | 62 mm |
| Rake | 5 mm | 4.5 mm | 45 mm | 45 mm | 45 mm |
| Trail | 110 mm | 107 mm | 101 mm | 97 mm | 97 mm |
| Seat Tube Angle | 75.5 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73 ° | 73 ° |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Newest 1.0 completes the Fuji Newest model. Fuji launched 46 bikes of this model so far. Take a sneak peek at all Fuji Newest bikes models from 2012, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
General Road bikes average price
Our math shows that the average cost of a dependable General Road bike is 1915$. However, you could also get a good General Road bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The Newest 1.0 2012 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Newest 1.0 has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
