Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset 105, Tiagra -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Altair 1 Compact aluminum with Power Diamond shape down tube, Double water bottle mounts
Suspension Fork
FC-770 Fuji Bonded Carbon Integrated w/ 1 1/8" Alloy Steerer
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano Tiagra, 31.8mm for triple
Shift Levers
Shimano Tiagra STI shifter/brake, 27-speed Flight Deck compatible
Cassette
Sunrace CSR-969, 11-25T 9-speed
Crank
FSA Omega MegaExo, w/Integrated spindle, 30/39/50T Alloy outer chainrings
Bottom Bracket
FSA MegaExo Exterior Bearing System
Chain
Sunrace CNM-94, 9-speed
Pedals
VP Resin Road w/clips and straps
Wheels
Front Hub
Alex AKX-R1.0 28H
Rear Hub
Alex AKX-R1.0, 32H
Rims
Alex AKX-R1.0 Double Wall Aluminum, 700c clincher
Spokes
14G Stainless Steel
Tires
Road Sport, 700 X 25c
Brakes
Brakes
Tektro R-350 dual pivot
Brake Levers
Tektro RL-570 Top Mount
Cockpit
Stem
Fuji Adjustable Road, 1 1/8" threadless
Handlebar
Fuji 6061 Butted Road, 26mm Anatomical Drops
Headset
V.P. 1 1/8" Standard Semi Cartridge, with convex hollow alloy spacer
Seat
Saddle
Fuji Anatomical Saddle
Seatpost
Fuji Comp MicroAdjust Forged Alloy, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 46cm | 50cm | 54cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.42 mm | 1.5 mm | 1.46 mm | 1.5 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 584 mm | 587 mm | 584 mm | 595 mm | 619 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69.5 mm | 63.2 mm | 60 mm | 57 mm | 56.9 mm |
| Stack | 515 mm | 538.6 mm | 568.9 mm | 575.5 mm | 610 mm |
| Reach | 382.5 mm | 378.8 mm | 379 mm | 393 mm | 407 mm |
| Top Tube Length | 513 mm | 533 mm | 548 mm | 568 mm | 593 mm |
| Seat Tube Angle | 76 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 105 mm | 126 mm | 156 mm | 161 mm | 197 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 996 mm | 999 mm | 997 mm | 1007 mm | 1032 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Standover Height | 713 mm | 742 mm | 776 mm | 798 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Newest 1.0 (US) is a Fuji Newest model. Fuji launched 46 bikes of this model so far. Take a sneak peek at all Fuji Newest bikes models from 2009, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for General Road bikes
Our math shows that the average cost of a dependable General Road bike is 1915$. However, paying less money than this amount doesn’t mean that you couldn’t get a great General Road bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
General Road bikes average weight
If we make a quick analysis of the average weight of a General Road bike, we get 9 kg (19.84 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 10.74 kg (23.68 lbs), Fuji bike is much heavier than average. In other words, this model is 19.33% heavier than the average General Road bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Fuji Newest 1.0 (US) 2009, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Newest 1.0 (US) has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
