Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, Sora -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Altair 1 Compact aluminum with Power Diamond shape down tube, Double water bottle mounts
Suspension Fork
FC-770 Fuji Bonded Carbon Integrated w/ 1 1/8" Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Tiagra GS
Front Derailleur
Shimano Sora, 31.8mm for triple
Shift Levers
Shimano Sora shifter/brake, 27-speed Flight Deck compatible
Cassette
Shimano HG-50, 12-25T 9-speed
Crank
FSA Vero Forged Aluminum 30/39/50T Chainring
Bottom Bracket
Sealed Cartridge Bearing ST
Chain
KMC Z-9000, 9-speed
Pedals
FPD Platform w/clips and straps
Wheels
Front Hub
Formula Alloy Road, 32H
Rear Hub
Formula Alloy Cassette Road, 9-speed, 32H
Rims
Alex R-500 Double Wall Aluminum, 32H 700c clincher
Spokes
14G Stainless Steel
Tires
Kenda K-152, 700 X 25c
Brakes
Brakes
Tektro R-310 Forged AL, dual pivot
Brake Levers
Tektro RL-570 Top Mount
Cockpit
Stem
Fuji Adjustable Road, 1 1/8" threadless
Handlebar
Fuji 6061 Butted Road, 26mm Anatomical Drops
Headset
V.P. 1 1/8" Standard Semi Cartridge w/Convex Alloy spacer
Seat
Saddle
Fuji Road Sport Anatomical
Seatpost
Fuji Comp Micro Adjust alloy, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.42 mm | 1.5 mm | 1.46 mm | 1.5 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 584 mm | 587 mm | 584 mm | 595 mm | 619 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69.5 mm | 63.2 mm | 60 mm | 57 mm | 56.9 mm |
| Stack | 515 mm | 538.6 mm | 568.9 mm | 575.5 mm | 610 mm |
| Reach | 382.5 mm | 378.8 mm | 379 mm | 393 mm | 407 mm |
| Top Tube Length | 513 mm | 533 mm | 548 mm | 568 mm | 593 mm |
| Seat Tube Angle | 76 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 105 mm | 126 mm | 156 mm | 161 mm | 197 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 996 mm | 999 mm | 997 mm | 1007 mm | 1032 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Standover Height | 713 mm | 742 mm | 776 mm | 798 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
NEWEST 2.0-USA is a Fuji Newest model. Fuji launched 46 bikes of this model so far. You can get a glimpse at all models from 2010, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
General Road bikes average price
If you want to purchase a solid General Road bike, it is important to know that the average cost is 1915$. However, this doesn’t mean that if you spend less money on a General Road bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
General Road bikes average weight
The average weight for General Road bikes is 9 kg (19.84 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
much heavier than average, NEWEST 2.0-USA has a weight of 10.64 kg (23.46 lbs). In conclusion, the average General Road bike weighs 18.22% less than NEWEST 2.0-USA.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the NEWEST 2.0-USA model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
