Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Claris, Shimano -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A1-SL Compact Aluminum with traditional round down tube, Double water bottle mounts
Suspension Fork
Fuji custom tapered CrMo, 1 1/8" Steerer
Drivetrain
Rear Derailleur
Shimano RD-2300, 8sp
Front Derailleur
Shimano FD-2303, 31.8mm clamp
Shift Levers
Shimano SL-R400 D/T shifter, 24-speed
Cassette
Shimano HG-50, 12-25T 8sp
Crank
Fuji Forged Alloy 30/42/52T Chainring
Bottom Bracket
Sealed Cartridge Bearing ST
Chain
KMC Z-72, 8sp
Wheels
Rims
Fuji Alloy 32H hubs w/Fuji Alloy Clincher w/CNC sidewalls, 700c
Tires
Kenda K-152, 700x25c, Wire bead
Brakes
Brakes
Fuji Forged Alloy, dual pivot
Brake Levers
Fuji Forged Alloy
Cockpit
Stem
Fuji Adjustable Road
Handlebar
Fuji Alloy Anatomical Drops
Headset
VP A-88 Sealed 1 1/8"
Seat
Saddle
Fuji Road Sport Anatomical
Seatpost
Fuji Comp MicroAdjust Forged Alloy, 350x27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.42 mm | 1.5 mm | 1.46 mm | 1.5 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 263 mm | 263 mm |
| Front Center | 584 mm | 587 mm | 584 mm | 595 mm | 619 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 68 mm | 61 mm | 58 mm | 56 mm | 56 mm |
| Stack | 515 mm | 538.6 mm | 568.9 mm | 575.5 mm | 610 mm |
| Reach | 382.5 mm | 378.8 mm | 379 mm | 393 mm | 407 mm |
| Top Tube Length | 513 mm | 533 mm | 548 mm | 568 mm | 593 mm |
| Seat Tube Angle | 76 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 105 mm | 126 mm | 156 mm | 161 mm | 197 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 996 mm | 999 mm | 997 mm | 1007 mm | 1032 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Standover Height | 713 mm | 742 mm | 776 mm | 798 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Newest 4.0 completes the Fuji Newest model. Fuji released 46 bikes variations of this model so far. You can easily view all of the Fuji Newest bikes models from 2011, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
General Road bikes average price
Our math shows that the average cost of a dependable General Road bike is 1915$. However, you could also get a good General Road bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
General Road bikes average weight
General Road bikes have an average weight of 9 kg (19.84 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 11.4 kg (25.13 lbs), the Newest 4.0 model is much heavier than average. In short, the average General Road bike weight is 26.67% lower than this one.
Newest 4.0 components
Fork material
Newest 4.0 has a steel fork, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
As for the wheels, Fuji Newest 4.0 2011, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
