Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Claris, Shimano -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Altair 1 Compact aluminum with traditional round down tube, Double water bottle mounts
Suspension Fork
Fuji 1 1/8" custom tapered Cro-Moly, Aero Road
Drivetrain
Rear Derailleur
NEW Shimano 2300
Front Derailleur
NEW Shimano FD-2303, 31.8mm for triple
Shift Levers
Shimano SL-R400 D/T shifter, 24-speed
Cassette
Shimano HG-50, 12-25T 8-speed
Crank
Fuji Forged Aluminum Road 30/42/52T Chainring
Bottom Bracket
Sealed Cartridge Bearing ST
Chain
KMC Z-72, 8sp
Pedals
FPD Platform Road
Wheels
Front Hub
Fuji Alloy Road, 36h
Rear Hub
Fuji Alloy Road, 8-speed, 36H
Rims
Star Circle J-14S Double Wall Aluminum, 32H 700c clincher
Spokes
14G Stainless Steel
Tires
Road Sport, 700 X 25c
Brakes
Brakes
Tektro R-310 Forged AL, dual pivot
Brake Levers
Tektro RL-570 Top Mount
Cockpit
Stem
Fuji Adjustable Road Aluminum, Removable Clamp
Handlebar
Fuji Alloy Road
Headset
VP A-88 Sealed 1 1/8"
Seat
Saddle
Fuji Road Sport Anatomical Saddle
Seatpost
Fuji Comp Alloy Micro Adjust, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.42 mm | 1.5 mm | 1.46 mm | 1.5 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 584 mm | 587 mm | 584 mm | 595 mm | 619 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69.5 mm | 63.2 mm | 60 mm | 57 mm | 56.9 mm |
| Stack | 515 mm | 538.6 mm | 568.9 mm | 575.5 mm | 610 mm |
| Reach | 382.5 mm | 378.8 mm | 379 mm | 393 mm | 407 mm |
| Top Tube Length | 513 mm | 533 mm | 548 mm | 568 mm | 593 mm |
| Seat Tube Angle | 76 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 105 mm | 126 mm | 156 mm | 161 mm | 197 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 996 mm | 999 mm | 997 mm | 1007 mm | 1032 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Standover Height | 713 mm | 742 mm | 776 mm | 798 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
NEWEST 4.0-USA completes the Fuji Newest model. There are 46 bikes that carry this model name. Take a sneak peek at all Fuji Newest bikes models from 2010, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
General Road bikes average price
Our math shows that the average cost of a dependable General Road bike is 1915$. However, this doesn’t mean that if you spend less money on a General Road bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for General Road bikes
If we make a quick analysis of the average weight of a General Road bike, we get 9 kg (19.84 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
NEWEST 4.0-USA weighs 11.66 kg (25.71 lbs) and is much heavier than the average. In short, the average General Road bike weight is 29.56% lower than this one.
Overview of components
Fork material
NEWEST 4.0-USA has a steel fork, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The wheels on NEWEST 4.0-USA are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji NEWEST 4.0-USA is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
