Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 ultra high-modulus aero carbon tubing, integrated seat clamp, integrated head tube, water bottle mount
Suspension Fork
FC-330 carbon aero monocoque w/ 1 1/8" carbon steerer, integrated airfoil brakes
Drivetrain
Rear Derailleur
Shimano Ultegra Di2, 11-speed
Front Derailleur
Shimano Ultegra Di2, braze-on mount
Shift Levers
Shimano Ultegra Di2 6871 TT/Tri, 22-speed
Cassette
Shimano Ultegra, 11-25T, 11-speed
Crank
Oval 720 hollow forged, 53/39T
Bottom Bracket
Press-fit BB86 sealed bearing
Chain
KMC
Pedals
N/A
Wheels
Rims
Oval 981 full-carbon clincher
Tires
Vittoria Rubino Pro Slick, 150 tpi, 700c x 23mm
Brakes
Brakes
TRP aero TTV
Brake Levers
Shimano Ultegra TT/Tri Di2 6871
Cockpit
Stem
Oval 760 aero, 31.8mm, 8 degrees
Handlebar
Oval 950 carbon base bar w/ 950 S bend carbon extensions
Headset
FSA press-fit top/integrated bottom bearing, 1 1/8"
Seat
Saddle
Oval R700T Triathlon w/ CrMo-Ti hollow rails
Seatpost
Oval aero carbon multi-position
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.24 mm | 1.21 mm | 1.2 mm | 1.24 mm | 1.26 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 575 mm | 590 mm | 621 mm | 635 mm | 653 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 59 mm | 59 mm | 46 mm | 59 mm | 62 mm |
| Stack | 493 mm | 498 mm | 508 mm | 545 mm | 570 mm |
| Reach | 396 mm | 410 mm | 425 mm | 440 mm | 454 mm |
| Top Tube Length | 500 mm | 515 mm | 532 mm | 555 mm | 572 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 473 mm | 482 mm | 488 mm | 522 mm | 539 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 85 mm | 90 mm | 100 mm | 140 mm | 164 mm |
| Chainstay Length | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Wheelbase | 965 mm | 980 mm | 1011 mm | 1025 mm | 1044 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 775 mm | 783 mm | 790 mm | 826 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
About this model
Norcom Straight 1.3 completes the Fuji Norcom model. Fuji launched 39 bikes of this model so far. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Triathlon bikes average price
According to our calculations, the average cost of a Triathlon bike that is reliable is 4177$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Triathlon bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Triathlon bikes
If we make a quick analysis of the average weight of a Triathlon bike, we get 8.9 kg (19.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Fuji Norcom Straight 1.3 it’s weighing 8.53 kg (18.81 lbs). At this weight, is slightly lighter than average. In other words, this model is 4.34% lighter than the average Triathlon bike.
Overview of components
Fork material
Norcom Straight 1.3 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The Norcom Straight 1.3 2014 bike is equipped with 700c carbon wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Norcom Straight 1.3 is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 162 cm – 199 cm (5.31 ft – 6.53 ft). In short, you can easily find one that suits you.
