Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 ultra high-modulus aero carbon tubing, integrated seat clamp, integrated head tube, water bottle mount
Suspension Fork
FC-330 carbon aero monocoque w/ 1 1/8" carbon steerer, integrated airfoil brakes
Drivetrain
Rear Derailleur
Shimano Ultegra Di2, 11-speed
Front Derailleur
Shimano Ultegra Di2, braze-on mount
Shift Levers
Shimano Ultegra Di2 6871 bar end TT, 11-speed
Cassette
Shimano Ultegra, 11-25T, 11-speed
Crank
Shimano Ultegra, 53/39T
Bottom Bracket
Shimano, BB86 press-fit
Chain
KMC X11SL w/ Missing Link, 11-speed
Pedals
N/A
Wheels
Rims
Oval 980 full-carbon clincher, 16 / 20h
Tires
Vittoria Rubino Pro, 700 x 23, 150 tpi, folding
Brakes
Brakes
TRP aero TTV
Brake Levers
Shimano Ultegra TT/Tri Di2 6871
Cockpit
Stem
Oval Concepts 760 Aero, 3D-forged 7075 alloy, 31.8mm, +/- 8°
Handlebar
Oval Concepts 950, carbon base bar w/ 950 S bend carbon extensions
Headset
FSA, 1 1/8" press-fit top/integrated bottom bearing
Seat
Saddle
Oval Concepts R700T w/ CrMo-Ti hollow rails
Seatpost
Oval Concepts, aero carbon, multi-position
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.24 mm | 1.21 mm | 1.2 mm | 1.24 mm | 1.26 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 575 mm | 590 mm | 621 mm | 635 mm | 653 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 58.8 mm | 58.8 mm | 58.8 mm | 58.8 mm | 58.8 mm |
| Stack | 493 mm | 498 mm | 508 mm | 545 mm | 570 mm |
| Reach | 396 mm | 410 mm | 425 mm | 440 mm | 454 mm |
| Top Tube Length | 500 mm | 515 mm | 532 mm | 555 mm | 572 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 473 mm | 482 mm | 488 mm | 522 mm | 539 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 85 mm | 90 mm | 100 mm | 140 mm | 164 mm |
| Chainstay Length | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Wheelbase | 965 mm | 980 mm | 1011 mm | 1025 mm | 1044 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 775 mm | 783 mm | 790 mm | 826 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
About this model
Norcom Straight 1.3 completes the Fuji Norcom model. Fuji released 39 bikes variations of this model so far. Check out the entire range from 2016 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Triathlon bikes average price
Our math shows that the average cost of a dependable Triathlon bike is 4177$. However, this doesn’t mean that if you spend less money on a Triathlon bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Triathlon bikes average weight
If we make a quick analysis of the average weight of a Triathlon bike, we get 8.9 kg (19.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Norcom Straight 1.3 weighs 8.6 kg (18.96 lbs) and is slightly lighter than the average. In conclusion, the average Triathlon bike weighs 3.49% more than Norcom Straight 1.3.
Norcom Straight 1.3 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The Norcom Straight 1.3 2016 bike is equipped with 700c carbon wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Norcom Straight 1.3 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
Norcom Straight 1.3 comes in 5 sizes, that range from 162 cm – 199 cm (5.31 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
