Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C5 high-modulus aero carbon tubing, integrated seat clamp, integrated head tube w/ height-adjust, water bottle mount
Suspension Fork
FC-440 carbon aero monocoque w/ 1 1/8" carbon steerer, integrated airfoil brakes
Drivetrain
Rear Derailleur
Shimano 105, 10-speed
Front Derailleur
Shimano Tiagra, braze-on mount
Shift Levers
Microshift Bar End TT shifters, 20-speed
Cassette
Shimano Tiagra, 11-25T, 10-speed
Crank
Oval 520 forged alloy, 50/34T
Bottom Bracket
Press-fit BB86 sealed bearing
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Oval 327 aero alloy clincher, 20/24H precision road hubs, stainless bladed spokes
Tires
Vittoria Zaffiro Pro Slick, 60 tpi, 700c x 23mm
Brakes
Brakes
TRP aero TTV
Brake Levers
Oval 701 forged alloy
Cockpit
Stem
Oval 760 aero, 31.8mm, 8 degrees
Handlebar
Oval 750 alloy base bar w/ 750 S bend alloy extensions
Headset
FSA No. 36 press-fit top/integrated bottom bearing, 1 1/8"
Seat
Saddle
Oval R500T Triathlon w/ CrMo hollow rails
Seatpost
Oval aero carbon multi-position
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.24 mm | 1.21 mm | 1.2 mm | 1.24 mm | 1.26 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 575 mm | 590 mm | 621 mm | 635 mm | 653 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 59 mm | 59 mm | 46 mm | 59 mm | 62 mm |
| Stack | 493 mm | 498 mm | 508 mm | 545 mm | 570 mm |
| Reach | 396 mm | 410 mm | 425 mm | 440 mm | 454 mm |
| Top Tube Length | 500 mm | 515 mm | 532 mm | 555 mm | 572 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 473 mm | 482 mm | 488 mm | 522 mm | 539 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 85 mm | 90 mm | 100 mm | 140 mm | 164 mm |
| Chainstay Length | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Wheelbase | 965 mm | 980 mm | 1011 mm | 1025 mm | 1044 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 775 mm | 783 mm | 790 mm | 826 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
Model Overview
Norcom Straight 2.5 is a Fuji Norcom model. Fuji launched 39 bikes of this model so far. You can easily view all of the Fuji Norcom bikes models from 2014, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Triathlon bikes average price
If you want to purchase a solid Triathlon bike, it is important to know that the average cost is 4177$. However, even if your budget is less than the average, you might still be able to get a top-quality Triathlon bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Triathlon bikes average weight
On a deeper look, we notice that the average weight of a Triathlon bike is 8.9 kg (19.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 9.06 kg (19.97 lbs), the Norcom Straight 2.5 model is slightly heavier than average. In other words, this model is 1.8% heavier than the average Triathlon bike.
Norcom Straight 2.5 components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Norcom Straight 2.5 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Norcom Straight 2.5 has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
This bike is available in 5 sizes. They vary from 162 cm – 199 cm (5.31 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
