Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Fork Fox Float 32
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6°€SL alloy, custom°€butted, semi°€integrated tapered headset w/ 1.5" lower bearing, hydroformed top and down tube
Suspension Fork
Fox 32 FLOAT Evolution CTD w/ 15mm thru axle, tapered alloy steerer, 120mm travel
Rear Shock
Fox Float Evolution CTD
Drivetrain
Rear Derailleur
Shimano Deore XT, M786 SGS Shadow plus, 10-speed
Front Derailleur
Shimano SLX, M676, 34.9mm
Shift Levers
Shimano SLX, M670 Rapid Fire, 20/30-speed
Cassette
Shimano Deore HG62, 11-36T, 10-speed
Crank
Shimano SLX, M675 hollow Tech II w/ integrated spindle, 40/28T
Bottom Bracket
Shimano BB91 press-fit
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Shimano SLX M678 32H Center Lock disc hubs, Sun Inferno 23
Tires
Schwalbe Nobby Nic, Evo 26" x 2.25" folding, 67 tpi
Brakes
Brakes
Shimano SLX M675, hydraulic disc, 180mm/160mm rotor
Brake Levers
Shimano SLX M675 hydraulic disc w/ Inspec
Cockpit
Stem
Oval M613, 3D-forged alloy, 31.8mm clamp diameter, 6° rise
Handlebar
Oval M600, alloy riser bar, 9° sweep, 31.8mm diameter, 710mm wide, 15mm rise
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval M600 w/ hollow CrMo rails
Seatpost
Oval M600, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.45 mm | 1.37 mm | 1.3 mm | 1.22 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Stack | 579.9 mm | 579.9 mm | 579.9 mm | 579.9 mm | 579.9 mm |
| Reach | 363.1 mm | 399.5 mm | 424.5 mm | 445.5 mm | 474.5 mm |
| Top Tube Length | 546.6 mm | 583 mm | 608 mm | 628 mm | 658 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 482 mm | 533 mm | 584 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 125 mm | 125 mm | 125 mm | 125 mm | 125 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1047 mm | 1083 mm | 1108 mm | 1128 mm | 1158 mm |
| Standover Height | 779 mm | 790 mm | 790 mm | 786 mm | 792 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
Model Overview
Outland 1.1 D belongs to the Fuji Outland model. Fuji launched 69 bikes of this model so far. You can get a glimpse at all models from 2013, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
Trail bikes weigh an average of 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Fuji Outland 1.1 D it’s weighing 12.78 kg (28.18 lbs). At this weight, is slightly lighter than average. In conclusion, the average Trail bike weighs 1.56% more than Outland 1.1 D.
Outland 1.1 D components
Fork
The fork installed on this bike is the Fox Float 32 model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The wheels on Outland 1.1 D are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Outland 1.1 D has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
