Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Manitou
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL alloy, custom-butted, w/ PowerCurve down tube, oversized seat tube, water bottle mount
Suspension Fork
Manitou Marvel LTD w/ remote lockout, tapered alloy steerer, 15mm Thru axle, 120mm travel
Rear Shock
Manitou Radium Expert
Drivetrain
Rear Derailleur
Shimano Deore XT shadow, 10-speed
Front Derailleur
Shimano Deore, 34.9mm
Shift Levers
Shimano Deore, Rapid Fire, 20/30-speed
Cassette
SunRace Driven, 11-36T, 10-speed
Crank
Shimano Deore, hollow Tech II w/ integrated spindle, 38/24T
Bottom Bracket
Shimano sealed cartridge
Chain
KMC X10 w/ MissingLink, 10-speed
Pedals
N/A
Wheels
Rims
Vera Terra DPD22 rim 32h, Formula DC-51 front / DC-308 rear disc hubs, stainless black spokes
Tires
Schwalbe Rapid Rob, 29" x 2.25", 50tpi
Brakes
Brakes
Shimano 396, hydraulic disc, 180/160mm rotor
Brake Levers
Shimano 396, hydraulic disc
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, 7° rise
Handlebar
Oval Concepts 250, 6061 alloy, flat, 31.8mm, 9° sweep, +/- 5mm rise, 710mm wide
Headset
FSA NO.42B, 1 1/8" - 1.5", caged bearings
Seat
Saddle
Oval Concepts 200 w/ steel rails
Seatpost
Oval Concepts 300, 6061 alloy, 30.9mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.45 mm | 1.42 mm | 1.39 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 658 mm | 690 mm | 709 mm | 729 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 92 mm | 92 mm | 92 mm | 92 mm |
| Stack | 605 mm | 605 mm | 614 mm | 624 mm |
| Reach | 384 mm | 416 mm | 432 mm | 448 mm |
| Top Tube Length | 564.2 mm | 596.2 mm | 615.2 mm | 634.1 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533.4 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1111 mm | 1143 mm | 1163 mm | 1182 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 782 mm | 782 mm | 782 mm | 782 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Outland 1.1 Disc is part of the Fuji Outland model. Fuji released 69 bikes variations of this model so far. You can easily view all of the Fuji Outland bikes models from 2015, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The Manitou is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
As for the wheels, Fuji Outland 1.1 Disc 2015, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Outland 1.1 Disc has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
