Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Fork RockShox Recon Gold RL
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL alloy, custom-butted, semi-integrated tapered headset w/ 1.5" lower bearing, hydroformed top and down tube
Suspension Fork
RockShox Recon Gold Solo Air w/ tapered alloy steerer, 120mm travel
Rear Shock
RockShox Monarch RL
Drivetrain
Rear Derailleur
Shimano Deore XT, M781 SGS Shadow, 10-speed
Front Derailleur
Shimano SLX, M676, 34.9mm
Shift Levers
Shimano SLX, M670 Rapid Fire, 20/30-speed
Cassette
Shimano Deore HG62, 11-36T, 10-speed
Crank
Shimano SLX, M675 hollow Tech II w/ integrated spindle, 40/28T
Bottom Bracket
Shimano cartridge bearings
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Shimano SLX M678 front / M675 rear, 32H Center Lock disc hubs, Sun Inferno 23 rims
Tires
Schwalbe Racing Ralph, 26" x 2.25" folding, 67 tpi
Brakes
Brakes
Shimano Deore M615 hydraulic, 180mm/160mm rotor
Brake Levers
Shimano Deore M615 hydraulic
Cockpit
Stem
Oval M313, 3D-forged alloy, 31.8mm clamp diameter, 6° rise
Handlebar
Oval M200, alloy riser bar, 9° sweep, 31.8mm diameter, 710mm wide, 15mm rise
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval M400 w/ CrMo rails
Seatpost
Oval M300, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.45 mm | 1.37 mm | 1.3 mm | 1.22 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Stack | 579.9 mm | 579.9 mm | 579.9 mm | 579.9 mm | 579.9 mm |
| Reach | 363.1 mm | 399.5 mm | 424.5 mm | 445.5 mm | 474.5 mm |
| Top Tube Length | 546.6 mm | 583 mm | 608 mm | 628 mm | 658 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 482 mm | 533 mm | 584 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 125 mm | 125 mm | 125 mm | 125 mm | 125 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1047 mm | 1083 mm | 1108 mm | 1128 mm | 1158 mm |
| Standover Height | 779 mm | 790 mm | 790 mm | 786 mm | 792 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
About this model
Outland 1.3 completes the Fuji Outland model. There are 69 bikes that carry this model name. Check out the entire range from 2014 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Trail bikes average weight
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Fuji Outland 1.3 it’s weighing 12.88 kg (28.4 lbs). At this weight, is slightly lighter than average. In other words, this model is 0.78% lighter than the average Trail bike.
Outland 1.3 components
Fork
This bike has the RockShox Recon Gold RL fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
As for the wheels, Fuji Outland 1.3 2014, has a 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Outland 1.3 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
