Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Fork RockShox Recon Gold RL
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6°€SL alloy, custom°€butted, semi°€integrated tapered headset w/ 1.5" lower bearing, hydroformed top and down tube
Suspension Fork
RockShox Recon Gold Solo Air w/ tapered alloy steerer, 120mm travel
Rear Shock
RockShox Monarch RL
Drivetrain
Rear Derailleur
Shimano Deore XT, M781 SGS Shadow, 10°€speed
Front Derailleur
Shimano SLX, M676, 34.9mm
Shift Levers
Shimano SLX, M670 Rapid Fire, 20/30-speed
Cassette
Shimano Deore HG62, 11-36T, 10-speed
Crank
Shimano SLX, M675 hollow Tech II w/ integrated spindle, 40/28T
Bottom Bracket
Shimano cartridge bearings
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Shimano SLX M678 front / M675 rear, 32H Center Lock disc hubs, Sun Inferno 23 rims
Tires
Schwalbe Nobby Nic, 26" x 2.25" folding, 67 tpi
Brakes
Brakes
Shimano Deore M596 hydraulic, 180mm/160mm rotor
Brake Levers
Shimano Deore M596 hydraulic
Cockpit
Stem
Oval M213, 3D-forged alloy, 31.8mm clamp diameter, 6° rise
Handlebar
Oval M200, alloy riser bar, 9° sweep, 31.8mm diameter, 710mm wide, 15mm rise
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval M400 w/ CrMo rails
Seatpost
Oval M200, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.45 mm | 1.37 mm | 1.3 mm | 1.22 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Stack | 579.9 mm | 579.9 mm | 579.9 mm | 579.9 mm | 579.9 mm |
| Reach | 363.1 mm | 399.5 mm | 424.5 mm | 445.5 mm | 474.5 mm |
| Top Tube Length | 546.6 mm | 583 mm | 608 mm | 628 mm | 658 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 482 mm | 533 mm | 584 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 125 mm | 125 mm | 125 mm | 125 mm | 125 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1047 mm | 1083 mm | 1108 mm | 1128 mm | 1158 mm |
| Standover Height | 779 mm | 790 mm | 790 mm | 786 mm | 792 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
Model Overview
Outland 1.3 D completes the Fuji Outland model. Fuji launched 69 bikes of this model so far. You can get a glimpse at all models from 2013, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Outland 1.3 D components
Fork
The Outland 1.3 D comes factory-installed with the RockShox Recon Gold RL fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
Outland 1.3 D has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The Outland 1.3 D 2013 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
