Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork SunTour XCR
-
Groupset Alivio -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL alloy, custom-butted, w/ PowerCurve down tube, oversized seat tube, water bottle mount
Suspension Fork
SR Suntour SF15-XCR-LO-R w/ hydraulic lockout, tapered alloy steerer, 15mm Thru axle, 120mm travel
Rear Shock
Manitou Radium Comp
Drivetrain
Rear Derailleur
Shimano Alivio, 9-speed
Front Derailleur
Shimano Alivio, 34.9mm
Shift Levers
Shimano Alivio, Rapid Fire, 9-speed
Cassette
Shimano HG300, 12-36T, 9-speed
Crank
Shimano Alivio, Octalink, 40/30/22T
Bottom Bracket
Shimano Octalink sealed cartridge
Chain
KMC X9, 9-speed
Pedals
Alloy platform
Wheels
Rims
Vera Terra DPD18 rim 32h, Formula DC-51 front / DC-22 rear disc hubs, stainless black spokes
Tires
Schwalbe Rapid Rob, 29" x 2.25", 50tpi
Brakes
Brakes
Tektro HD-M290, hydraulic disc, 180/160mm rotor
Brake Levers
Tektro HD-M290, hydraulic disc
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, 7° rise
Handlebar
Oval Concepts flat bar, 6061 alloy, 31.8mm, 9° sweep, 0mm rise, 710mm wide
Headset
FSA NO.42B, 1 1/8" - 1.5", caged bearings
Seat
Saddle
Oval Concepts 200 w/ steel rails
Seatpost
Oval Concepts, 6061 alloy, 30.9mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.45 mm | 1.42 mm | 1.39 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 658 mm | 690 mm | 709 mm | 729 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 92 mm | 92 mm | 92 mm | 92 mm |
| Stack | 605 mm | 605 mm | 614 mm | 624 mm |
| Reach | 384 mm | 416 mm | 432 mm | 448 mm |
| Top Tube Length | 564.2 mm | 596.2 mm | 615.2 mm | 634.1 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533.4 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1111 mm | 1143 mm | 1163 mm | 1182 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 782 mm | 782 mm | 782 mm | 782 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
Outland 1.3 Disc belongs to the Fuji Outland model. 69 bikes variations carry this model name so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
Fuji Outland 1.3 Disc 2015 bike is equipped with the SunTour XCR fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
As for the wheels, Fuji Outland 1.3 Disc 2015, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
