Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Manitou
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL alloy, custom-butted, semi-integrated tapered headset w/ 1.5" lower bearing, hydroformed top and down tube
Suspension Fork
Manitou Tower Comp TS air w/ tapered alloy steerer, lockout, 100mm travel
Rear Shock
Manitou Radium Expert w/ lockout
Drivetrain
Rear Derailleur
Shimano Deore XT, M781 SGS Shadow, 10-speed
Front Derailleur
Shimano Deore, M611, high direct mount
Shift Levers
Shimano Deore, M610 Rapid Fire, 10-speed
Cassette
Shimano Deore HG62, 11-36T, 10-speed
Crank
OVAL 430 w/ integrated spindle, 44/32/22T
Bottom Bracket
Praxis Works sealed cartridge
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Formula DC-73 front / DC-30 rear, 32H alloy disc hubs, Vera Terra DPD22 rims
Tires
Hutchinson Cobra, 29" x 2.1", 33 tpi
Brakes
Brakes
Promax Decipher, hydraulic disc, 180mm/160mm rotor
Brake Levers
Promax Decipher hydraulic disc
Cockpit
Stem
Oval M313, 3D-forged alloy, 31.8mm clamp diameter, 6° rise
Handlebar
Oval M100, alloy flat bar, 9° sweep, 31.8mm diameter, 710mm wide
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval M200 w/ steel rails
Seatpost
Oval M300, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.45 mm | 1.38 mm | 1.31 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 648 mm | 689 mm | 711 mm | 734 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 92 mm | 92 mm | 92 mm | 92 mm |
| Stack | 620 mm | 620 mm | 620 mm | 620 mm |
| Reach | 387.1 mm | 428.5 mm | 450.5 mm | 473.5 mm |
| Top Tube Length | 546.6 mm | 588 mm | 610 mm | 633 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 432 mm | 482 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 125 mm | 125 mm | 125 mm | 125 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1092 mm | 1134 mm | 1156 mm | 1179 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 809 mm | 809 mm | 808 mm | 809 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
Outland 29 1.5 belongs to the Fuji Outland model. There are 69 bikes that carry this model name. You can easily view all of the Fuji Outland bikes models from 2014, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 13.93 kg (30.71 lbs), Fuji bike is considerably heavier than average. In short, the average Crosscountry bike weight is 12.34% lower than this one.
Overview of components
Fork
Fuji Outland 29 1.5 2014 bike is equipped with the Manitou fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When leaving the production line, the Outland 29 1.5 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Outland 29 1.5 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
